DRK ZWV 0301 Multifunctional V belt Fatigue Testing Machine Electronic

Product Overview

Description

DRK-ZWV-0301 Multifunctional V-belt Fatigue Testing Machine



Product Introduction



This test machine is used to measure the fatigue life of ordinary V-belt, general narrow V-belt, and washing machine V-belt. The V-belt is installed on the two pulleys of the testing machine. After applying the specified tension, the torque is applied at a certain speed. The operation was performed to measure the rate of change of the center distance of the V-belt after 24 hours and whether the V-belt reached a predetermined fatigue life. Each time, two V-belt fatigue tests can be performed, and the length measuring function can be used as a length measuring machine, and fatigue testing and length measurement of other belt types can also be performed. Frequency control, digital display speed and running time, adjustable speed, retain the data after the V-band breaks. The operation is convenient, the design is novel, the appearance is beautiful, and the reliability is high.

The testing machine meets the requirements of GB/T 1171-1996 "General V-band", GB/T 15328-2009 "General V-band Fatigue Test Method (No Torque Method)", GB/T 12730-2002 "General Narrow V-band", HG/T 242-2001 "Washing Machine V-band" and JISK 6323-1989 "General V-band".



Product Characteristics



1. Touch screen man-machine interface, PLC control, frequency conversion speed regulation, and retain the data after V-band breaks.

2. Vertical rack, accurate loading

Technical parameter

1. Maximum speed of driving wheel: 0-4000r/min (variable frequency adjustable)

2. Speed limit deviation: +2%

3. Tension force and test range:



Product name	Product model	Tensioning force(N)	Sample base length (mm)
V-belt of washing machine	XM	300	500~1300
	XZ	300	500~1300
	XSPZ	500	500~1300
	XA	500	500~1500
common V belt	A	290±5	890~1100
	B	390±10	1370~1760
		780±10
Fatigue test method for common V-band and narrow V-band	SPZ	600±10	800~2500
	SPA	1000±10	800~2500
	SPB	1300±10	800~2500



4. Cumulator timing range: 1-999999h

5. Power supply: AC380V + 10% 50Hz three-phase four-wire system (must have zero wire)

6. Outward Size: 700mm x 650mm x 1850mm

7. Machine weight: 220 kg
