Product Overview

Description


Product Description

◇ Aerogel is an ultra-light solid material with nano-porous structure. Because of its extremely low density, it is also called "frozen smoke" or "blue smoke".


 ◇ It has won the Guinness Book of Records "the world's lightest solid". Since more than 80% of the aerogel is air, it has a very good heat insulation effect.


◇ The one-inch thick aerogel is equivalent to the insulation function of 20 to 30 ordinary glass. Even if the aerogel is placed between the rose and the flame, the rose will not be damaged.

Detailed Images

1.\tLow thermal conductivity is only 1/3 to 1/5 of traditional materials.

2.\tDrowning rate >99.5% moisture absorption rate <0.5%.

3.\tHigh fire rating: fire performance A1, smokeless, no droplets, no harmful gases.

4.\tGreen environmental protection: non-toxic materials without corrosion.

5.\tConvenient construction: aerogels are thin, tensile and compressive. Low density and light weight. The utility knife can be cut without the need for professional tools and equipment.

6.\tLong service life: aerogel has a unique three-position network structure, long-term use shrinkage rate ≤1% at 650 °C, and no melt sintering, powdering, aerogel is an inorganic material, UV long-term exposure is not aging, weather

resistance Good service life can reach more than 20 years.

Product Type
\t
GR0852-1200B
\t
Product Form:
\t
Plate
\t
Thickness:
\t
3~50mm
\t
Maximum Plane Size:
\t
800mm×2000mm
\t
Thermal Conductivity:
\t
0.15W/( m.K)( 1200℃)
\t
Maximum Use Temperature:
\t
1200℃
\t
Density:
\t
300~350kg/m3
\t
Fire-proof Level:
\t
A1 Level(GB/T 8624-2012)
\t
Compressive Strength:
\t
0.15MPa(Normal temperature,deformation 5%)
\t
Hydrophobic:
\t
<0.5% (GB/T 205480-2008)
\t
Main Applicaton:
\t
Mechanical properties for thermal insulation materials, special occasions for high temperature insulation
\t
GR0852-1000J
\t
Product Form:
\t
Coil
\t
Thickness:
\t
3~50mm
\t
Maximum Plane Size:
\t
1000mm/1500mm
\t
Thermal Conductivity:
\t
0.1W/(m.K)( 1200℃)
\t
Temperature:
\t
1000℃
\t
Density:
\t
300~350kg/m3
\t
Hydrophobic:
\t
<0.5% (GB/T 205480-2008)
\t
Main Applicaton:
\t
Used in special occasions of high temperature insulation.
\t
GR0852-800J
\t
Product Form:
\t
Coil
\t
Thickness:
\t
3~50mm
\t
Maximum Plane Size:
\t
1000mm/1500mm
\t
Thermal Conductivity:
\t
0.018W/(m.K)( 800℃)
\t
Maximum Use Temperature:
\t
800℃
\t
Density:
\t
165~170kg/ m3
\t
Fire-proof Level:
\t
A1Level (GB/T 8624-2012)
\t
Hydrophobic:
\t
<0.5% (GB/T 205480-2008)
\t
Main Applicaton:
\t
Thermal power plants, chemical plant piping equipment; steel insulation; all kinds of high and low temperature furnaces.
\t
GR0852- 650J
\t
Product Form:
\t
Coil
\t
Thickness:
\t
3~50mm
\t
Width:
\t
1000mm/1500mm
\t
Thermal Conductivity:
\t
0.020W/(m.K)( 650℃)
\t
Maximum Use Temperature:
\t
650℃
\t
Density:
\t
160~165kg/ m3
\t
Fire-proof Level:
\t
A1Level (GB/T 8624-2012)
\t
Hydrophobic:
\t
<0.5% (GB/T 205480-2008)
\t
Main Applicaton:
\t
Thermal power plant chemical plant pipeline equipment;prefabricated insulation; all kinds of high and low temperature furnace body; heavy oil production evaporation pipeline; high speed train, automobile, subway and other car body insulation; construction.
Product Applications


1.In the field of architecture, it can be used for insulation of building wall, roof floor and glass curtain .



2.The main application point is the transportation vehicle's heat insulation, as well as the new energy vapor protection of lithium battery.





3. In the field of household insulation and cold chain logistics, instead of traditional materials, it is used as an insulation layer to greatly improve the insulation effect and increase the internal volume.

4. In functional equipment, aerogel jackets and other outdoor products made with aerogel ultra-thin interlayers have unmatched warmth and are truly lighter, thinner and warmer.

5.Military application Fighter cabin insulation

Packing & Delivery

Packaging Details:Carton packaging or according to customer needs

Port:Shanghai , China / Guangzhou , China
