1600kg Rider Electric Stacker Powered Pallet Lifter Maximum lifting height 4.0m

Price:RUB 269,153.90 - RUB 299,481.10

Quantity:

Rider Electric Stacker

Advantages

.Capacity 1.0t/1.2t/1.5t, lift height 1.6-3.5ton, free duplex mast can be choose

·Double lift cylinders make lift more stable

·Stepless speed control, slow travel switch optional.

·both walkie and platform can choose,strong chassis bearing heavy duty.

·CURTIS controller, German MAHLE hydraulic motor and German Lenze brake

·Excellent stability for high level stacking.

680 680 4.jpg 1000k00kg 3000m

3300mm 4000m Bias Walkie Powered Electric Stack

1.6T Electric Stacker Parameter
Model		ES-16B
Driving style		Walkie/Rider
Load capacity Q	kg	1600
Load center C	mm	600
Overall length L1	mm	1960
Overall width W	mm	875
Min. overall height H1	mm	2050	1750	2050	2200	2350
Fork dimension L×b×m	mm	1150/1200×160×56
Outside width of forks D	mm	560/680
Ground clearance x	mm	≥30
Base distance L0	mm	1283
Wheel material		PU
Driving wheel size	mm	φ250×80
Front wheel size	mm	φ78×70
Balance wheel size	mm	φ125×75
Min. steering radius Wa	mm	1540
Min. width of aisle	mm	≥2400
Max. height of forks H	mm	1600	2500	3000	3300	3500
Max. overall height H2	mm	2070	2970	3470	3770	3970
Min. height of forks H3	mm	90
Travel speed(laden/unladen)	km/h	4.5/5.5
Lift speed(laden/unladen)	mm/s	90/160
Lower speed(laden/unladen)	mm/s	95/120
Brake type		Electromagnetic
Power of driving motor	kw	1.2
Power of lift motor	kw	2.2
Battery capacity/voltage	Ah/V	165/24, 240/24
Weight of battery	kg	160/210
Net weight(without battery)	kg	610	690	705	720	735

1000kg 1200kg 3000mm 3300mm 4000mm Bias Walkie Powered Electric Stacker
