Elevator automatic rescue device for hospital

Product Overview

Description

About us

1. Hospital lift is not only used to convey the passengers.It has been put with the special and strict requirements because of its special use ,fucction and performance.LINGZ hospital lift can accurately control the lift running speed with smooth and comfortable operation.


2. LINGZ hospital lift lays stress on the humane design.It fully optimizes the car structure and satisfies the customer·s using demands to the max .ettent.It provides the passengers with a quiet and elegant space.


3. LINGZ hospital lift creats a harmonious unity to the hospital environments by its unique design ideal.It brings about a bright and clean space.It furnishes the passengers with a cozy atmosphere.The patients will be more confident about their recovery by using such kind of the beautiful lift.



Elevator automatic rescue device for hospital

1.Elevator specifications

Speed	Pit	Top floor	load	Opening net width	Car net size	Hoistway net size
m/s	PP	OH	kg	JJ	AA BB	AH BH
1.0	1400	4200	1600	1100	1400 2400	2300 2900
1.5	1500	4500				2550 2900
						2550 2900
1.75	1700	4700				2550 2900
2.0 2.5	2000	5100	2000	1200	1600 2750	2350 3300
						2700 3300
3.0	2200	5300				2700 3300

2.Car net size inside

Capacity   load(kg)	Car size   (width*depth)mm	Car area
2000	1500*2700	≤4.2
1600	1400*2400	≤3.56

The advantageous perfoumances

1.Accurate open and shut control

Door installations in the frequency control mode.Converter can be very accurate speed control cabin doors open and close to a safer ride the elevators.

2.The cozy and quite atmosphere

The pursuit of maximum comfort by ladder,reflecting concern by creating very enjoyable to use space.Ceiling design and brignt,elegant car wide variety of wall colors for your choice.Car operating panel using advanced computer graphics technology,from top to bottom with elegant new streamlined design.

3.Stable and smooth running

Motor part of the VVVF inverter control system with precise control of motor speed,so that thactor voice has become smaller.

4.The highly reliable decentralized control

Microcomputer with a common elevator decentralized control over the distributed control system room,car,car operating panel and hall monitors are installed hou ladder of high performance micro-computer,you can accurately and quickly control all the time changing information.On the lines of communication between the microcomputer to detect,thus enhancing the reliability of the system.

Functions List of Elevator

• with/without drive operation


• Automatic return to the base landing


• Automatic landing


• Call cancel when begin reverse-running


• Cage door opening when elevator arrives the floor where there is a hall call


• Door opening / closing call indication


• Indication in the cage when hall calling


• Self-Learning of shaft data


• Full load non-stop operation


• Overload alarm, Car Operating panel display: “OL”


• Alarming device


• In-car and m/r inter talk device


• Light and fan auto-control


• Elevator Locking Device


• Door closing time auto delaying


• False-call canceling


• Emergency Light


• Driven over current protection


• Door opening / closing time-limited protection


• Rope sliding protection


• Door Nudging


• Trouble self-diagnosis and memory


• Over speed falling protection


• Top/Bottom landing overpass protection


• Inspection Operation


• Floor display


• Light curtain protection with mechanical safety edge


• Fireman’s return switch
