Product Overview

Description

Raygleam Flexible panel use unique shingled cells technology. The panel made with conducting resin paste without ribbon to minimizes the optical and resistive losses, improve mechanical load to flexing over 30 degrees, and are able to withstand harsh weather conditions and are almost impervious to corrosion.
Key Features
★ The latest Shingled PERC solar cells technology.
★ Over 30 degrees of ultimate bending no cells cracks.
★ Improved 15~20% power of output than the traditional panel.
★ Minimizes the optical and resistive losses.
★ 10 years workmanship and materials warranty.
★ OEM and ODM supported.
Specification
Typical Electrical Data
at STC: lrradiance 1000 W/m2 module temperature 25°C AM=1.5;
Model
RG-FLX100M-M
Pmax (W)
100W
Power Tolerance
0 ~ +3%
Vmp (V)
19.86
Imp (A)
5.04
Voc (V)
23.7
Isc (A)
5.34
Working Temperature
-40°C ~+ 85°C
Nominal Operating cell temperatures
45± 2°C
Temperature coefficient of Pmax
-0.4%/ °C
Temperature coefficient of Voc
-0.3 %/ °C
Temperature coefficient of Isc
0.06 %/ °C
Temperature coefficient of Vmpp
-0.35 %/ °C
Nominal Voltage
12V
Max. System Voltage
1000Vdc
Max. Fusing Current
10A
Mechanical Data
Cells Type
Prime Monocrystalline PERC solar cells
Module Dimensions (L/W/H) (mm)
1150*510*4
Module weight
2.5kg
Cell's Efficiency
21.40%
Front Cover (material/ thickness)
Higher Strength TPT/ETFE/ 2.2mm
Back Sheet (color)
White/ Black
Bending Range
≧30°
Junction Box (protection degree)
≧IP65/IP68 with by-pass diode
Grommets
316 stainless Steel /6 Mounting holes/Squre & Round corners
Cables & Connectors
0.5 m/2.5&4.0mm2/MC4 compatible/IP68
Product Details
Advantages of Shingling Technology
1. More Light & Flexible
2. More Higher Efficiency
3. Better Shading Performance
4. Higher Reliability
Stringent Quality Control System
