CK20 China high precision super small mini cnc lathe machine
- Category: >>>
- Supplier: Tengzhou Sosen Co. Ltd.
Share on (62132892095):
Product Overview
Description
CK20 China high precision super small mini cnc lathe machine
Product Description
Feature:
CK20, CK30 small size precision CNC lathe is designed to meet the need for efficient and accurate automation production of medium to small diameter parts.
This kind of China high precision super small mini cnc lathe machine is fitted with standard .
Equipment of C-axis comtour control and optional accessory of revolving tools(for drilling ,slot Milling and rigid tapping), fiexible and combined machining makes it a fact on comb type tool rest lathe that composite machining equals single set up.
Specifications:
| Capacity | Swing over bed | Ø240mm |
| Swing over cross slide | Ø120mm | |
| Max. maching diameter | Ø100mm | |
| Max. maching length | 100mm | |
| Spindle | Spindle speed | Max.6000r/min |
| Number of spindle speed ranges | Stepless | |
| Through hole diameter | 20F/FC/FA 30F/FC/FA: Ø20mm/Ø30mm | |
| Spring collet shank | 20F/FC/FA: Ø26mm | |
| 30F/FC/FA: Ø36mm | ||
| Axes | X-axis travel traverse | 20m/min |
| Z-axis rapid traverse | 20m/min | |
| X-axis travel | 200mm/250mm(Optional) | |
| Z-axis travel | 180mm | |
| Motor | Spindle drive motor | 20F/30F:2.2/3.7KW |
| 20FA/30FA/20FC/30FC:3.7/5.5KW | ||
| Feed motor | 0.75KW | |
| Required electric power | 6KVA | |
| Floor space | 1240*1360*1580mm | |
| Height from floor to spindle center | 985mm | |
| Mass of machine | 1100KG | |
| Size | 1900*1490*1940mm | |
Standard accessories:
| Coolant device with chip tank | 1 Set |
| Lighting unit | 1 Set |
| Automatic slide surface lubricate | 1 Set |
| Air lube unit | 1 Set |
| Air type chuck opening /closing device | 1 Set |
| Collet chuck blank | 1 piece |
| Spindle split chuck adapter | 1 piece |
| Preset base | 1 Set |
| S1,S2 Tool holders S | 2 pieces each |
| Tool holders S3/AH1/pulling - out device | 1 Set |
| I.D Tool holder | 1 Set |
| Milling collet chuck | 1 Set |
| Tools and tool box | 1 Set |
| Circuit breake | 1 Set |
| Machine base | 4 piece |
| Machine vinyl cover | 1 Set |
| Signal lamp | 1 Set |
| Spindle split chuck | 4 piece |
| Air blower system | 1 piece |
| Part total preset counter | 1 Set |
| Spindle locking device (mechanical locking device) | 1 Set |
| C Contouring control(only FC type) | 1 Set |
Packing & Shipment
Company Information
FAQ
Q1.How to send my enquiry?
You can contact us by email, phone call, message (Whats APP, We Chat, Skype).
Q2.How long can I get feedback after enquiry?
We will reply you within 3 hours in working day.
Q3.Delivery time
Machines order takes 30 days after deposit payment received. Please inquiry sales.
Q4.What is the package? Is it suitable for shipment?
Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.
Q5.Payment term
30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to inquiry sales.
Q6.Can I trust you?
Sure, we’re Alibaba Gold Suppliers, Alibaba Assessed Supplier, Alibaba Trade Assurance Supplier.
Q7.How long is the warranty for machines?
Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing. Please contact our SOSEN sales representative for details.
Q8.How about your after-sale service?
Our after sales support and service is second to none and we urgently respond to your queries, if parts are required they would be sent to you by international courier within 3 days.
