Economic Microcomputer Full automatic Screen Printing Machine

Product Overview

Description

Performance and Features

1.  Microcomputer with fault graph display function for maintenance
2.  Four cylinders motorized to achieve even pressure with clear mesh
3.  With dual-stage adaptive systems, easy adjustment and precise positioning
4.  With frequency converter, independent speed adjustment of squeegee blade, suitablefor
     different printing areas
5.  Printing process driven by crank





Specification:

ITEM	FB-4060	FB-6080	FB-6090
Max printing size	400*600mm	600*800mm	600*900mm
Max screen frame size	700*800mm	850*1000mm	850*1100mm
Printing table size	600*700mm	800*900mm	800*1000mm
Max printing speed	1300t/h	1200t/h	1200t/h
Overall dimension(L*W*H)	1380*780*1300mm	1620*980*1300mm	1620*1080*1300mm
Power	3P4N 50/60HZ     380V 2.6KW	3P4N 50/60HZ     380V 3KW	3P4N 50/60HZ     380V 3KW
