Edge Bending Machine for steel base cylinder making pre press
- Category: >>>
- Supplier: Shanxi Yubo International Trading Co. Ltd. [Shanxi China]Shanxi
Share on (62136012283):
Product Overview
Description
Product Description
The Edge Bending Machine is for bending the steel plate to a certain Angle can make the submerged arc welder find a better balance during the operation of the plate coiler.
The Parameters
a, Nominal power: 1000KN
b, Table length: 2000mm
c, Wall panel distance: 1400mm
d, Throat Depth: 300mm
e, Slide route: 120mm
f, Maximum opening height: 390mm
g, Maximum hydraulic pressure: 20MPa
h, Slide speed: No-load: 80mm / s
Work: 8mm / s
Return: 60mm / s
i, Main motor power: 7.5KW
j, Axial piston pump: 25MCY14-1B
k, Overall dimensions (length × width × height) 2110 × 1700 × 2495
l, Machine Weight (approx.): 5300Kg
The Configuration
1.Oil pump
low-noise oil pump Shaoyang vic
2.Modle
Jiangsu taizhou
3.Motor
Shandong Kaiyuan Electric Co., Ltd.
4.Main seal
NOK
5.Digital display
Nanjing eston Company
E10
6.Electrical cabinet
Taizun
7.Electrical Parts
Delixi
8.Hydraulic valve
Taiwan Gold oil
Packing & Delivery
The machine is tightly packed with winding film, and then the customized wooden box is nailed, and then the goods are delivered to the dock through a special transportation company. The container is reinforced again to ensure the goods are delivered to your factory intact.
