Vertex зажимы для гидравлических станков VH 6 1/фрезерные гидравлические тиски 0 300 мм

 New Arrival China Good Hydraulic Machine Vise For Die

Manufacturing Industry

Product function and feature:

1. The built-in oil pressure vise, boost design, as long as the instantaneous force taps the handle, that is automatically

converted into boost feed;

2. The body and the fixed tiger mouth are formed as a whole. The FC30 cast iron is made of strong steel and is not easy

to deform.

3. The slip surface of the vise is heat treated at HRC 45 degree or above and ground precisely.

4. Clamps are made of alloy steel, hardened by heat treatment, and then grinded precisely.

5. The lower half of the vise is made of high ductile cast iron, which can resist the inclination or bending of the vise. The

sliding surface is ground after hardening and heat treatment.

6. The hydraulic clamping force can be adjusted freely from the lines on the hydraulic rod. When a small force is applied,

the force can be amplified by the function of the hydraulic propulsor, and then the incomparable clamping force can be

produced.

7. The clamping range can be adjusted freely according to the size of the workpiece. When the clamping range is adjusted

to the third hole, the clamping range is larger than that of the general vise.

8. The special structure of the hydraulic supercharger can provide a stable clamping force and resist vibration. The clamping

of the workpiece can increase its shock absorption in cutting by means of the force of the spring installed in the hydraulic

cylinder. This function is unique to the hydraulic vise.

Application:

Suitable for general milling machine, CNC numerical control milling machine, machine processing, die manufacturing industry
