WestLake Goodride Chaoyang brand AD713 11R22.5 12R22.5 275/70R22.5 295/80R22.5 TBR Bus Tyre All Steel Radial Truck Tires
- Category: >>>
- Supplier: Shenzhen Mammon Auto Parts Co. Ltd.
Share on (62137579851):
Product Overview
Description
WestLake Goodride Chaoyang brand AD713 11R22.5 12R22.5 275/70R22.5 295/80R22.5 TBR Bus Tyre All Steel Radial Truck Tires
Benefits and Features
- Ultra deep tread with robust tread blocks features excellent wet traction and longer tyre life
- Drive axle applicable providing lateral stability and multiple retreads
- Latest carcass technology guarantees superior footprint and enchanced damage resistance
| Size | LR/PR | Service index | Tread Depth (mm) | Standard Rim | Overall Diameter (mm) | Section Width (mm) | Max. Load Capacity at Cold Inflation Pressure | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Dual | |||||||||||||
| (kg) | (lbs) | (kPa) | (psi) | (kg) | (lbs) | (kPa) | (psi) | |||||||
| 11R22.5(AD713) | G/14 | 144/142L | 22.6 | 8.25 | 1065 | 279 | 2800 | 6175 | 720 | 105 | 2650 | 5840 | 720 | 105 |
| 11R22.5(AD713) | H/16 | 148/145L | 22.6 | 8.25 | 1065 | 279 | 3150 | 6940 | 850 | 123 | 2900 | 6390 | 850 | 123 |
| 12R22.5 | J/18 | 152/149L | 23.0 | 9.00 | 1096 | 300 | 3550 | 7830 | 930 | 135 | 3250 | 7160 | 930 | 135 |
| 275/70R22.5(AD713) | H/16 | 148/145L | 18.5 | 8.25 | 958 | 276 | 3150 | 6940 | 900 | 130 | 2900 | 6395 | 900 | 130 |
| 295/80R22.5(AD713) | H/16 | 150/147M | 20.0 | 9.00 | 1050 | 298 | 3350 | 7390 | 830 | 120 | 3075 | 6780 | 830 | 120 |
| 295/80R22.5(AD713) | J/18 | 152/149M | 20.0 | 9.00 | 1050 | 298 | 3550 | 7830 | 900 | 131 | 3250 | 7160 | 900 | 131 |
| 315/80R22.5 | J/18 | 154/151M(156/150L) | 22.5 | 9.00 | 1082 | 312 | 3750 | 8270 | 830 | 120 | 3450 | 7610 | 830 | 120 |
