AIR BREAKER PNEUMATIC BREAKER Pick Jack Hammer Kit

Product Overview

Description

AIR BREAKER PNEUMATIC BREAKER COMPRESSOR Demo Pick Jack Hammer Kit

HG series pneumatic hammer splitter is powered by compressed air which is decentralized in turn to both ends of the cylinder by the tubular distributing valve. The impact hammer reciprocating motion strike onto the shank end of the point rod, which will be drilled into the rock, and break it into pieces.



Technical data:

Air pressure(Mpa):0.5

Air consumption(L/s):≤23

Impact frequency(HZ):>15.5

Machine length(mm):600

Machine weight(Kg):12.5

Air hose inner diameter(mm):16
