Fully Automatic Square Bottom Big Brown Kraft Shopping Paper Bag Making Machine Price For Sale
- Category: >>>
- Supplier: Zhejiang Lifeng Machinery Co. Ltd.
Share on (62143997266):
Product Overview
Description
Fully Automatic Square Bottom Big Brown Kraft Shopping Paper Bag Making Machine Price For Sale
Introduction
This machine forming the paper bag in one process from roll paper, edge folding, tube forming, cutting, gluing, bottom folding, bottom gluing and finishing bag. Easy operation, low power consumption, high efficiency. It is an ideal machine for producing food bags like bread bags, KFC bags and McDonald's bags.
Features
1.Controls bag length freely in a range through the human-machine interface
2.Adopt touch screen and PLC programmable control system, the work condition can be shown real time.
3.Equipped with an accurate photocell system for printed mark tracking
4.Color mark error stopping system
5.Double photoelectric sensor limit automatic correction control system
6.Material lifting adopt pneumatic lift structure.
7.Automatic lubrication system
This machine forming the paper bag in one process from roll paper, edge folding, tube forming, cutting, gluing, bottom folding, bottom gluing and finishing bag. Easy operation, low power consumption, high efficiency. It is an ideal machine for producing food bags like bread bags, KFC bags and McDonald's bags.
Features
1.Controls bag length freely in a range through the human-machine interface
2.Adopt touch screen and PLC programmable control system, the work condition can be shown real time.
3.Equipped with an accurate photocell system for printed mark tracking
4.Color mark error stopping system
5.Double photoelectric sensor limit automatic correction control system
6.Material lifting adopt pneumatic lift structure.
7.Automatic lubrication system
Main Technical Parameter | |
Cutting Length | 150-460 mm |
Bag Length | 145-455 mm |
Bag Width | 80-250 mm |
Gusset depth | 10-50 mm |
Standard flap | 12-20 mm |
Max. Speed | 400 pcs/min |
Max. reel weight | 400 Kg |
Max.Roll Diameter | 1000 mm |
Reel inner diameter | 76 mm |
Paper specification | 30-80 gsm |
Web edge control system | Yes |
Web tension control system | Yes |
Air pressure | ≥0.12cmm, 0.6~1.2Mpa |
Driven motor | Double servo motor |
Electric | 380V 50Hz, 3 phase |
Power | 6 KW |
Weight | 3000 Kg |
Overall dimension | 4580×1650×1850 mm |
