Secukey 433MHz Wireless Module Access Control Keypad Card Reader, Wiegand RFID Proximity Card Reader for Access Controller
- Category: >>>
- Supplier: Secukey Technology Co. Ltd.
Share on (62144642767):
Product Overview
Description
>>> Quick click to move to Secukey home page.
Secukey 433MHz Wireless Module Access Control Keypad Card Reader, Wiegand RFID Proximity 13.56MHz HF Card Reader for Access Controller
Product Description
> 433MHz Rolling Code technology
> PIN length: 1~6 digits
> 13.56MHz MF/IC Card
> Programmable Wiegand output of the Receiver: 26 bits or 34 bits
> Communication distance: 30m maximum
> Ultra low power consumption
Parameter
wireless keypd reader
| Wireless Keypad | PIN Length | 1-6 digits |
| Operating Voltage | 3 units of AAA batteries | |
| Idle Current Working Current | ≤5uA ≤45mA | |
| Reading Distance | ≤3cm | |
| Communication Frequency | 433MHz | |
| Communication Distance | 30m Maximum | |
| Operating Temperature | -20°C~+60°C (-4°F~+140°F) | |
| Operating Humidity | 0%~86% | |
| Physical | ABS | |
| Dimensions | L134 * W55* H20 (mm) | |
| Net Weight | 100g | |
| Receiver | Operating Voltage | 12V DC |
| Working Current | ≤15mA | |
| Communication Frequency | 433MHz | |
| Wiegand Output Format | 26 bits Or 34 bits (Default is 26 bits) | |
| Operating Temperature | -20°C~+60°C (-4°F~+140°F) | |
| Operating Humidity | 0%~86% | |
| Dimensions | L25 * W50 (mm) | |
| Net Weight | 10g | |
| Wireless Button (Optional Accessory) | Operating Voltage | 1unit of 2023 Lithium battery |
| Idle Current Working Current | ≤2uA ≤20mA | |
| Communication Frequency | 433MHz | |
| Communication Distance | 20m Maximum |
