Product Overview

Description

mig co2 welding wire AWS ER70S-6

1. Applications:

Used for welding low carbon steel and low alloy steel structures, especially for welding of thin plates and can be applied to carbon steels, ship building steel (A , B, D, E, A36, D36, E36) and equivalent mild steel or 550Mpa grade mild alloy steel, such as container buildings, bridge building, machinery manufacturing, railway construction, pressure vessels for semi-auto or automatic gas shielded welding and general welding purposes etc.

2. Product features:

is a kind of mild steel copper coated welding wire, suitable for 100% CO2 and argon and CO2 mixed gas protective welding with stable feasibility, good welding seams, less spatters and excellent welding process properties. Suitable for all-position welding work.

3.

Technical data:

A. Chemical composition: C 0.06-0.15, Mn 1.40-1.85, Si 0.80-1.15, P <=0.025, S <=0.035, Cu <=0.35, Ni <=0.30, Cr <=0.20

B. Tensile strength: ≥500MPa, yield point: ≥420MPa, elongation: ≥22, AK-V impact value: ≥27(-29)

4. Available size (diameter):

0.8mm / 0.9mm / 1.0mm / 1.2mm / 1.6mm

5. Available standard:

AWS ER70S-6

6. Packing:

4.5kg,4.7kg,5kg,15kg,18kg,20kg welding wire+ black plastic spool+ rust-proof paper+plastic packing+carton+pattle

GB/T ER50-6 DIN SG2 JIS YGW12
AWS ER70S-6 BS A18 EN G3Si1

 Wire Size

 Spool Size

 Net Weight

 0.8mm
1.0mm
1.2mm
1.6mm

 D100mm D200mm
D270mm D300mm K300mm

 1kg,5kg,15kg,18kg,20kg



chemical composition
of welding wire(%)

C

Mn

Si

P

S

Cr

Ni

Cu

0.06~0.15

1.40~1.85

0.80~1.15

≤0.025

≤0.035

-

-

≤0.20

Mechanical Properties
or
Deposited Metal

Yield strengthσ0.2(Mpa)

Tensile strengthσb(Mpa)

Elongationδ5(%)

AKV impact(J)

≥420

≥500

≥22

≥27(-29)
