Special offer semi hermetic 40hp Bezier type, Copelan,Frascode,Dorine,GEA Bock series compressor for refrigeration equipment
- Category: >>>
- Supplier: Taixing Jingchuang Penguin Refrigeration Equipment Factory (general Partnership)
Share on (62152260127):
Product Overview
Description
Product Overview
This is the Bitzer original compressor 3HP medium and low temperature, using BSE32 refrigerant, we also provide refrigerant, if
you need to contact us for details！
you need to contact us for details！
We are the manufacturer you are looking for,Our factory is also looking for agents and distributors all over the world tocooperate and develop together.
Product Description: | SEMI-HERMETIC RECIPROCATING COMPRESSORS(PENGUIN series) | |||||||||
Product Range: | 6.5HP-60HP | |||||||||
Specifications: | 40HP/30kW | |||||||||
Refrigeration Type: | R22 (R12/R502) ,R134a ,R404A ,R407C | |||||||||
Evaporating Temperature Range: | R22:-50~+12.5℃, R134a:-20~+12.5℃, R404A :-55~+7.5℃,R407C:-30~+5℃ | |||||||||
Primary Application: | Our products have same application like Bitzer compressors and other brands refrigeration compressor which can applied cold stroage, large refrigerated warehouse in the industry of Chemical, Refinery, Pharmaceutical, Restaurant, Supermarket, Factory workshop and Food,also can applied to Frozen Foods Equipments/ Potato Chips line /Full Line Frozen Food / Ice Cream Vending Machine /frozen sucker set /frozen stick confection producing line / ice sucker machine / ice candy producing/ ice cream machine / frozen yogurt machine/ Reliable Quick Frozen Machine / Green Soy Bean frozen vegetables and fruit processing line machinery | |||||||||
Tech. Data: | ||||||||||
Model | Motor Nominal Power | Displacement | Max operating current A | Fuel Supply mode | Weight | |||||
HP/kW | m3/h | A | Kg | |||||||
B503-4 | 5HP/3.7kW | 21.9 | 8.9 | Centrifugal lubrication | 92 | |||||
4VB6.5 | 6.5HP/4.7kW | 23.7 | 12.0 | Centrifugal lubrication | 105 | |||||
4VB8 | 8HP/5.5kW | 27.4 | 13.3 | Centrifugal lubrication | 94 | |||||
4VB8.5 | 8.5HP/6.3kW | 32.6 | 16.0 | Centrifugal lubrication | 135 | |||||
4VB20 | 20HP/15kW | 86.0 | 37.0 | Pressure lubrication | 208 | |||||
4VB25 | 25HP/18.5kW | 103.0 | 47.0 | Pressure lubrication | 208 | |||||
6WB30 | 30HP/22kW | 129.0 | 56.0 | Pressure lubrication | 210 | |||||
6WB30DS | 30HP/22kW | 103.0+52.0 | 56.0 | Pressure lubrication | 235 | |||||
6WB40 | 40HP/30kW | 154.4 | 76 | Pressure lubrication | 210 | |||||
8WB50 | 50HP/37kW | 187 | 94 | Pressure lubrication | 310 | |||||
8WB60 | 60HP/45kW | 206 | 115 | Pressure lubrication | 320 | |||||
All models default to medium& low temperature applications,We also accept customization of high temperature application. | ||||||||||
OUR STRENTHS
Compressor workshop assembly
1) High efficiency
Good reliability,high cooling capacity with short time ,low noise,small vibration and no leakage.
Refrigerant
2) Wide range of applications
Compressor uses R22 as refrigerant.R134a, R404a, R407b and R407c are also approved.Can be used in all kinds of refrigeration devices, many condensing units are used in penguin compressor.
Seal waterproofing test
3) Excellent performance
The compressor has scientific structure design, strict material selection, rigorous process and strict inspection.We have avariety of certificates, such as CCC, CE and so on. We also welcome you to inspect the site anytime and anywhere in our factory
workshop
4) Reliable safety device
The compressor is equipped with a motor protector and exhaust temperature monitor to prevent the motor and compressor from
overheating and running beyond the approved application pressure. We also have a warranty to protect your rights and interests if there is any damage.
The compressor has scientific structure design, strict material selection, rigorous process and strict inspection.We have avariety of certificates, such as CCC, CE and so on. We also welcome you to inspect the site anytime and anywhere in our factory
workshop
4) Reliable safety device
The compressor is equipped with a motor protector and exhaust temperature monitor to prevent the motor and compressor from
overheating and running beyond the approved application pressure. We also have a warranty to protect your rights and interests if there is any damage.
Successful Project
Why Choose Us
PENGUIN is a professional manufacturer for refrigeration compressors machinery in China.With the scientific progressive conception of rapid introduction, we make our machinery cover all over the overseas market. We have been producing our goods with mature techniques and first-class quality.
We warmly welcome customers all over the world to visit our manufacture.
We warmly welcome customers all over the world to visit our manufacture.
FAQ
Q: What is your MOQ?
A: 1PCS.
A: 1PCS.
Q: Are you a factory?
A: Yes, we are a reliable factory.
A: Yes, we are a reliable factory.
Q: How about your delivery time?
A: About 5-10 days if the goods are in stock. Or it is 15-45 days if the goods are not in stock, it is according to quantity.
A: About 5-10 days if the goods are in stock. Or it is 15-45 days if the goods are not in stock, it is according to quantity.
Q: Is there any discount?
A: Surely, different qty with different discount
A: Surely, different qty with different discount
