High quality Automatic A3 UV flatbed printer for leather, t shirt, garment, cloth, wood, glass, phone case cover, DTG printing

Share on:

Price:RUB 205,972.26
Price in USD:Details


Product Overview


Product Description


High quality Automatic A3 UV flatbed printer for leather, t shirt, garment, cloth, wood, glass, phone case cover, DTG printing

Model No. AC-A3UV
Print head 1 TX800 Print head
Print Resolution 1440*720 dpi
Printing speed 3.59sqm/h
Print head adjustable height 0-15cm
Printing size 30*50cm MAX
Height Adjust Automatic
Distance of print head printing 1-3mm(1mm is the best)
Ink color 4 or 5 Color(CMYK or CMYK+White)
Ink supply system CISS
Ink consumption 10-15mL/ square meter
Ink cartridge type Refillable
Min ink drop size 1.5pL
Interface Net
Rip software  Photoprint/ Onyx(Optional)
Normal Working environment Temperature:18-30 Celsius,Humidity:40-60%, clean room, low dust, less sun light
Power AC 110/220V,50HZ/60HZ
Package size 92*77*74cm wooden case
NW/GW 90KG/120KG


Detailed Images

1.One TX800 print head give CMYK+White 5 color UV ink.


2.Drag chain from Germany, High quality.


3.Big Volume, One ink tank is 1000mL . Continuous Ink Suply System.


4.Hiwin guide rail, it is mute, high precise.


5.The Aluminium oxide flatbed is A3 size. Horizontal error is below 0.02mm


1.Heavy-duty machine frame means best quality

2.Small size machine,the max print size is 30*50cm

3.1 pcs of LED UV light. UV ink is cured immediately. Media will be not out of shape because of the cold light.

4.CMYK+White 5 color ink. It can print only color or color and white at the same time.

5.Speed is fast. Only color,4 Pass,3.59sqm/h

6.High printing resolution can print minimum 0.8mm height letters



 The UV printer can print 3D effects and varnish picture on metal, glass, acrylic, ceramic, pleastic, leather, PVC, ABS, Carton, stone, Wall paper, Phone case, bottles, mugs, USB flash disk, golfballs,name card, etc


It can print Minimum 1mm letter:




 inkjet printer

Packaging & Shipping

 The machine is packaged in a wooden case. It is usually delivered by sea, by air or as customers request:_20190609180741.png


Buyer Feedback


Company Information

 Zhengzhou AllColor Digital Technology Co.,Ltd focus on foreign trade which will provide professional pre-sale service and after-sale service. we have our own factory who had been established for 21 years. It is a integrates factory who have research, design, production. So we can provide you good quality products, competitive price, reliable after-sale service and safe business.We believe long time business relationship come from honest service.

Allcolor factory


Q:Why Allcolor is the first choice for flatbed uv printer and supplies?

 A:1. Safe trading with Alibaba golden member.

    2.Extremely particular about products quality.

    3.1 year warranty, with lifetime online support.

    4.Availability of a wide range of products to suit almost every need about UV flatbed printer.

Q:How to buy?

A:Simply contact our sales expert and request for a proforma invoice.The order will be shipped after the invoice get paid.

Q:Do you ship internationally?

A:Yes.We ship internationally. With powerful backup of our regular forwarder, we ship to almost every places in the world by sea, air, train, truck and multimodal transport.Destination can be a port or a specific address.Contact us to get quote for shipping.

Q:How to pay?

A:Recommended payment method is bank transfer which usually has not much limitation in most countries.For small amount, there are some other options: Western Union.

Q:How is your warranty?

A:12 months trouble-free warranty.During warranty period, electric parts are covered with warranty.Users send back defective parts and we send the new one for replacement.

Q:How is your technical support?

A:Our English-speaking technician is available online via email, skype and whatsapp.Also, we can remote control your PC via TeamViewer to solve some software issue.

Please don't hesitate to contact us for more details, free samples and working videos of this machine

Please kindly check my number below:

Email:director at zzallcolor.com

WhatsApp/Wechat/Phone:+86 15038094036

Address:No.63,Unit 5,Building 3,No.27 Yard, Fengchan Road, Jinshui District, Zhengzhou City,Henan Province, China.
