Bucket elevator is our factory based on T type bucket elevator to develop new products, compared with T type bucket elevator, TH type bucket, bue to ascend machine has high hoisting height, stable operation and reliable, long life and other significant advantages.The main technical performance and parameters of the TH type bucket elevator conform to the international standard of vertical bucket elevator and foreign advanced standard;The TH type bucket elevator is used in the ring chain of high strength garden.

Model
Max Feed Size (mm)
Capacity (Ton/Hour)
Lifting Speed (m/s)
Belt Width (mm)
Lifting Height (m)
TD160
25
5.4-16
1.4
200
<40
TD250
35
12-35
1.6
300
<40
TD315
45
17-40
1.6
400
<40
TD400
55
24-66
1.8
500
<40
TD500
60
38-92
1.8
600
<40
TD630
70
85-142
2
700
<40
\t\t\t\t\t\t\t\t\tShape and size \t\t\t\t\t\t\t

1. The TH type bucket elevator conveyor is large, and the type with the same size and width is nearly twice as large as the HL type.

2. TH type bucket elevator adopts the assembly type sprocket.The wheel body and rim are connected with high strength bolts.

3. The lower part of the TH type bucket elevator adopts a heavy-hammer lever tensioning device, which can realize automatic tensioning.

4. TH type bucket elevator is a low-alloy high-strength ring chain with high tensile strength and abrasion resistance after proper heat treatment, with long service life.

Working Principle


Belt bucket elevator is composed of machine head, main frame,Maintenance cylinder,Ventilators, dustpan, dustpanbelt and machine base.

The materials are fed into the machine from the bottom and discharged from the top.
1. Firstly, the materials are evenly fed into the dustpan on the machine base;
2. Secondly, the materials are elevated into the machine head;
3. Thirdly, the raw materials are dumped into the targeted machine.
