HYDRAULIC FOUR WHEEL TYPE SCRAPER CONVEYOR
- Category: >>>
- Supplier: Shandong Hekuang Heavy Machinery Co. Ltd.
Share on (62155296546):
Product Overview
Description
Product Description
HYDRAULIC FOUR WHEEL TYPE SCRAPER CONVEYOR
This machine is a four-wheel drive, with large driving force, wide extraction range, full-section loading rock, no dead corners, no need manual auxiliary cleaning. This machine is a chain conveyor material, completely replacing the belt to conveying material, and using life increased more than 30 times. This machine adopts module production to facilitate downhole installation work, small body, compact structure, low gravity center, flexible maneuverability and stable work. It is an irreplaceable model of narrow section.
| HYDRAULIC FOUR WHEEL TYPE MUCKING LOADER MINING MACHINERY | ||
| Type | ZWY-STB-60L | ZWY-STB-100L |
| Loading capacity(m3/h) | 60 | 100 |
| Min.turning radius(mm) | 4500 | 4500 |
| Gradient(°) | <15(hard ground) | <15(hard ground) |
| Traveling speed(m/min) | 2-4.5m/min | 2-4.5m/min |
| Ground clearance(mm) | 200 | 210 |
| Nominal working pressure(Mpa) | 16/25 | 16/25 |
| Motor Power(kw) | 18.5/22 | 22/30 |
| Max.materials by size(L*W*H)MM | 810*580*500 | 810*580*500 |
| Applicable section(W*H)M | 2.0*2.0 | 2.2*2.2m |
| Weight(T) | 6.2 | 8.6 |
| Overall dimension(L*W*H) | 5800*1650*1700 | 5800*1700*1650 |
FAQ
Q: What is the delivery time ?
A: Normally the leadtime is 10 days after receipt of the deposit.
Q: What is the Payment terms ?
A: TT Or L/C.
Q: What is the warranty of the products ?
A: One year.
Q: Are you manufacturer or trading company ?
A: We are manufacturer,not dealer.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training.
Q: Can you customize the products as per request ?
A: Yes,we can customize your products.
Q: Where is the products are used?
A: The products are used for mining in the tunnel of coal mine or metal mine or non-metal mine.
Q: What is the drive mode of your products ?
A: The products drive mode is electric drive.
Q: Can the products be installed dual power –diesel engine and electric power ?
A: Yes,we can make the products with diesel engine and electric power
.
Q: What is the usage of the products ?
A: The products are multiple function integrating walking, digging,collecting,conveying,discharge.
