Cordierite Ceramic Honeycomb Plate For Gas Burner

Product Overview

Description

Cordierite ceramic honeycomb plate for gas burner

Cordierite ceramic honeycomb plate for gas burner

Hole type	Square hole	Round hole
Material	Cordierite	Cordierite
Volume	0.45-0.65g/cm3	0.45-0.65g/cm3
Hole density	200-320 hole/in2	260/280/320/520 hole/in2
Wall thickness	-	0.18-0.23/0.28-0.33/0.35- 0.40mm
Hole length	-	1.06/1.13/1.2mm
Hole diameter	1.12/1.25/1.42mm	-
Hole center distance	1.8/2.2/2.7mm	1.33-1.59mm
Holefraction	33.5-46.5%	63.5-73.5%
Water absorption rate	>46%	>40%
Thermal expansion coefficient	2.0-2.3×10-6	2.0-2.5×10-6
Thermal stability	850℃-25℃,Not cracking in 3 times	1200℃-25℃,Not cracking in repeated air cooling
Softening temperature	>1375℃	>1375℃
Surface burning temperature	1000℃-1200℃	1000℃-1200℃
Carbon monoxide release rate	≤80ppm	≤80ppm
Nitrogen oxide release rate	≤10ppm	≤10ppm
Compressive strength (longitudinal)	>13.0Mpa	>10.0Mpa
Compressive strength (lateral)	>6.0Mpa	>3.0Mpa
