Product Overview

Description



ARM processor with 1500MHz Quad-core CPU Hi3798MV200 Main chipset DVB-S2X+DVB-T2/C combo tuner built-in 8GB EMMC FLASH / 1GB DDR3 Memory 1x Common Interface slot (CI+) l Intemal 2.5” HDD Sata3 bracket (HDD Optional) Supported officially by OpenATV,OpenPLI www.Zgemma.org for more





You can use a USB Hard Disk Drive (HDD) to record all your favourite channels, listen to your music and watch a slideshow of your photos. What’s more, you can record up to 2 channels (on the same transponder) whilst watching a file from your USB HDD. You can even watch the .avi and .mkv file formats.



Make your TV screen more realistic, you can now watch channels in glorious High-Definition (HD), Full HD 1080p,4K Ultra HD 2160p with Dolby Digital Plus to give you a superior audio experience. It’s also 3D ready**.

It’s even Eco-friendly with 0.5W standby power consumption.

HbbTV Enjoy interactive services on your own living room. Zgemma is the "HbbTV" supported set-top box. "HbbTV", Hybrid Broadcast Broadband TV, is a major new pan-European initiative aimed at harmonizing the broadcast and broadband delivery of entertainment to the end consumer through connected TVs and Set-Top Boxes. In other words, HbbTV enables you to experience web browsing while watching the Live channel interactively at the same time. Main applications include TV Guide, Catch-up service, web video, VOD, or portal service. Additionally, you can check the weather, sports, news and etc,.







Specification: -



l Linux Operating System

l ARM processor with 1500MHz Quad-core CPU

l Hi3798MV200 Main chipset

l More than 4.10x linux kernel

l DVB-S2X+DVB-T2/C combo tuner built-in

l Support 4K- 2160p

l8GB EMMC FLASH / 1GB DDR3 Memory

l Picture in Picture (PIP)

l 1x smartcard reader

l 1x Common Interface slot (CI+)

l Intemal 2.5” HDD Sata3 bracket (HDD Optional)

l SD card (TF card) for recording, 8GB, 64GB, 128GB (optional)

l WIFI 300MHZ Built-in

l 2 x USB2.0

l 1x HDMI 2.0

l MPEG-2 / H.264 and H.265 Hardware Decoding

l HEVC / H.265 2160p60 Main-10 multi-format decoder

l 10/100 Mbit Ethernet Interface

l Multimedia plug-in supported

l Advanced EPG (Electronic Program Guide)

l User-friendly linux Menu system

l Full automatic service scan

l Various OSD skins supported

l Various Channel Editing Programs

l Easy and fast software-upgrade via USB

l Low deep-standby power consumption under 1 W

l Parental Control

l Plugin Service

l Excellent sound quality in Dolby Digital

l OSD into many languages and graphics (Skins)

l Web interface, WEB Remote control

l DiSEqC 1.0 / 1.1 / 1.2 and USALS

l External power supply 12V 3A



• Packaging & Shipping



  1 x Zgemma H9 COMBO Box

  1 x Remote Controller

  1 x Power Supply

  1 x HDMI Cable

  1 x User Manual

  2xWIFI Antenna



• Our Services



• Official DHL/FEDEX Partners(fast and safe delivery)
•



• Official Original Software Support www.zgemma.org





• Company Information







•
• FAQ



  Warranty : 1 year

  Delivery Time : DHL 3-4 days , Fedex 5-6days to Europe


  Payment Terms: T/T, Western Union, Paypal,ESCrow.

  Guarantee : Test the device 100% working well before shipping , make sure quick delivery time and offer best after-service for customers.





•  Note: We supply these receivers strictly as FTA only. We will not provide them with any patches pre-loaded and we can not help with any support for this. We provide support for the actual ZGEMMA hardware and for FTA reception only.
