Product Overview

Description



Products
























































Item name


Q500G6


Dimension


187*111*50mm(L*H*W)


Processor( support AES-NI)



Intel Celeron 3855U,1.6GHz,2M Cache,dual core ,                                  Intel HD Graphics 510

Intel Celeron 3865U,1.8GHz,dual core,                                                        Intel HD Graphics 610

Intel Core i3-6100U,2.3GHz,dual core,                                                       Intel HD Graphics 520

Intel Core i5-6200U,2.3GHz,to 2.8GHz,dual core,                                   Intel HD Graphics 520

Intel Core i7-6500U,2.5GHz,to 3.1GHz,dual core,                                     Intel HD Graphics 520



Memory(RAM)


DDR4L SO-DIMM Socket (Up 16G,2133MHz)


Storage


1x 2.5 inch HDD/SSD 1X full length Mini-PCIE for Msata


 LAN


6 * Intel I211-AT- 10/100/1000 Controller


WiFi


Option 1 : USB WIFI RT3070( by default)
Option 2 : Antheros PCIE WIFI (choose it,there will be 5 LAN works )

(For option 1,pls use it on AP mode Pfsense settings)



Audio Solution


Realtek ALC662 6-Channel HD Audio


Expansion port


1x SIM card slot , 2*RS-485(optional)


Front-Panel Connectors


power on/off button
HDD LED, Power LEDs
2 *USB 2.0 Ports
2 * USB 3.0 ports
Serial port: 1RS-232(COM 1)
HD Video port


Rear-Panel Connectors


12V DC input ,(DC Jack 5.5mm,2.5mm)
6* Intel RJ-45 Ports for Gigabit LAN
1 x Speak Out Connector


Support system


Preload pfsense,support linux Ubuntu,Windows 7/8/10 etc.







Attention




Here are all optional configurations. Any irequirements,pls contact me.

Memory:4G/8G/16G RAM
Hard disk: 8GB/ 16G/32G/64G/128G/256G/512GB Msata SSD
2.5" HDD: 500G or 1T


WIFI: optional



























Application Field
