Shanghai Dental Portable Ray X Film Machine

Product Overview

Description





Power Supply	AC100V-240V±10%  50/60Hz
Frequency	30KHZ
Battery	DC 14.8V 6400mA
Tube voltage	60KV
Tube current	1.5mA
Exposure time	0.1-2.0S
The distance from skin to cone	130mm
Tube focus	0.3*0.3mm
Rated power	60VA
Leak radiation	Outside one meter≤0.002mGy/h (National standard:0.25mGy/h)
Dimension	32*31*24cm
N.W	3kg
Optional color	Grey, Pink, Light green









 X Ray Sensor                                                           X Ray Sensor                                    PSP Imaing System



 SENSOR I                                                                 SENSOR II



1, The device is DC high frequency portable dental x-ray unit, small, light, and nearly no radiation.

2, There are manual buttons installed on the surface of shell, operate easily. all of the components are installed in the central PC board, insulation vacuum and sealed stereotype protection make its brilliant features.

3, The unit mainly suitable for oral pre-treatment diagnosis of internal organization structure and root depth and dental implant surgery.

4, The battery is durability, it can take about 500 images after full charged. and it can be charged and discharged for 1000 times in it's spanlife.

5, It can be connected with intra-oral digital x-ray imaging system.









Q1: Can i order one piece of dental X ray as sample?



A1: Yes, you can, the MOQ is one piece.



Q2: How could i know the shipping cost?



A2: Please tell us your delivery address with zip code, and then we will help you calculate the cheapest door to door shipping cost to you.



Q3: I don't have any experience of ordering such dental equipment before, can i order from you?



A3: Yes, you can, our professional freight forwarder will make sure you can receive the dental unit successfully.



Q4: How long is the warranty time?



Q4: Warranty time is one year.
