2 Axis Industrial toilet brush making machine
- Category: >>>
- Supplier: Zhengzhou Cambrian Machinery And Electronic Co. Ltd.
Share on (62166691303):
Product Overview
Description
toilet brush making machine
Product Description
toilet brush making machine
Description
Features of the Broom flocking machine
A.The workbench of TBI linear guide and high precision lead screw, operation is stable and
durable.
B.Interface guest to insert, delete, copy, hole, translation and other operation, simple and
convenient.
C.Maintain the cleanness of guide rail and screw, to avoid clutter adhesion on the guide rail or
screw, ensure the normal operation of machinery.
Introduction of Broom flocking machine
This machine is equipped with high speed servo drive big size of the plant garden, dedicated to
the production of flat broom type broom, workbench with Angle of tilt brush wire embedded,
spindle stop the remaining 2 axis servo stop, the speed of the spindle speed decided flocking.
Technical parameters of Broom flocking machine
|
Item |
Model |
M-NC3Z02S |
|
1 |
NO. of axis |
3-axis |
|
2 |
The stroke of X axis |
200mm rovide flexible customize for customer. |
|
The stroke of Y axis |
50mm rovide flexible customize for customer. |
|
|
The swing angle of Z axis |
±25° |
|
|
3 |
Setting of Worktable |
high-precision straight-line rail and ball screw,steady and durable. |
|
4 |
Material of Brush Handle |
Polyethylene, polystyrene, return materials, wood |
|
5 |
Material of Filaments |
PP,nylon,bristle,stainless steel,brass wire |
|
6 |
Application |
To tuft varieties of radial broom brushes |
|
7 |
Diameter of Filaments |
0.08mm-1.2mm |
|
8 |
The length of filament(outside the hole) |
40mm-120mm |
|
9 |
Diameter of hole |
2mm-8mm |
|
10 |
Colors of Brush Filaments |
single color or double colors |
|
11 |
Maximum Tufting Speed |
4 holes/second |
|
12 |
AC motor |
Delta Brake Motor |
|
13 |
Type&Brand of Driver/Motor |
stepper motor&driver , can adopt some brand motor&driver requested by users. |
|
14 |
Adjust Speed |
Frequency-conversion step less-adjustable speed |
|
15 |
Replaceable Fixture |
FMS type. It can be easily changed to make other kinds of brushes. |
|
16 |
Head mode |
Martin |
|
17 |
Programme Storage |
Store 2000 programme,each can input 100 thousand processing data. |
|
18 |
Program System |
CNC system,high precision,stability and efficiency |
|
19 |
Dimension(L*W*H) |
850×850×1400mm |
|
20 |
Gross weight |
360KG |
|
21 |
Power |
Single-phase 220v , 3-phase 220v or3-phase 380v, 50-60Hz |
|
22 |
Total power |
About 700w |
|
23 |
Compressed Air Pressure |
0.6-0.8Mpa |
Certifications
Packaging & Shipping
Packaging of sausage filling machine
One or two sets can be delivered by air or international express.
Shipping
We have been cooperating with several large transport agents and shipping
companies for long terms,the machines will be transported to you safety and
timely.
Delivery time
Normally, 5-7 days for preparing after receive your payment.
We will help confirm if we have machine in stock.
Our Services
toilet brush making machine
1.Before sending the machine,we will test and adjust,so you can use directly
when you get it.
2. Will send instruction book for you to checking the machine.
3.Any problems occur while using, professional advice will be given by us.
4.Can supply other meat machine and so on.
3.Any problems occur while using, professional advice will be given by us.
4.Can supply other meat machine and so on.
Company Information
toilet brush making machine
Zhengzhou Cambrian Machinery And Electronic Co., Ltd.is a professional manufacturer and exporter specialized in the R&D & Marketing of food machine.Our company has a professional team and in-depth study on the application of all kinds of machines and projects.
Our factory have been started from 1997, in the past decades, we have exported our machines to many countries,and established long term business relationship with customers.
FAQ
1. Do you have English manual book?
Yes, we have.Will send it to you with machine delivery.
2. Can we change the voltage?
Yes, please kindly inform me the voltage you need,220v,380v
3. How long will you send the machine after I pay?
Normally, 5-7 days
4. How can I pay?
By T/T(wire transfer),Western Union, Money Gram, Alibaba Trade Assurance
