Flexible Electronic Split Core CT MR 125 Solid Core Current Transformer Price
- Category: >>>
- Supplier: Wenzhou Everfar Electrical Co. Ltd.
Share on (62170726074):
Product Overview
Description
Product Description
CA/MES-CURRENT TRANSFORMERS
Fixing system: Busbar support mounting, metallic bracket panel mounting, by an accessory directly to cable by
MEASURING TRANSFORMERS
A range of (12 frames) compact design plastic case current transformer It's volume is much smaller than genera model, integral hinged plate terminal cover, DIN rail mounting all makes this series CT match the requiremens
TRANSFORMERS ELECTROINC USE
-These transformers are used for measuring current from 5A to 4000A, second current 5A/1A, cl. 1-cl02s. Busbar
dimensions from omm to 30X100mm
-These transformers are used for measuring current from 5A to 4000A, second current 5A/1A, cl. 1-cl02s. Busbar
dimensions from omm to 30X100mm
Features
Three built in fixing methods: panel/din rail/busbar
Built in hinged terminal cover
Compact design
Primary current from 5A to 3000A
Description
A range of compact plastic case current transformer.
Its volume is much smaller than general model.
Its integral hinged plate terminal cover and din rail mounting all make MES CT match requirements in space
limited panels.
Specifications
| Rated frequency | 50/60Hz |
| Rated test voltage | 3Kv AC (1 min) |
| Rated short-time thermal current (Ith) | 60In |
| 60In Rated dynamic current (Idyn) | 2.5Ith |
| Rated voltage (Um) | 0.72Kv AC |
| Continuous overload (Id) | 1.2In |
| Operating temperature | .-10 degree to 50 degree |
| Housing self-extinguishing class | VO |
| Safety factor | FS 5 |
| Secondary current | 5A/1A |
Standard
IEC60044-1 GB1208-2006
| Model | Primary / Secondary | Busbar Hole Dimensions(mm) | Rated Burden (VA) | Accuracy Class | Rated Voltage |
| CA-62/B | 5/5A~150/5A | busbar | 1.5~2.5 | 0.5 /1.0 | 0.72KV(AC) |
| CA-45/14 | 5/5A~60/5A | Φ=14mm | 1~2.5 | 0.5/1.0 | 0.72KV(AC) |
| CA-62/20 | 30/5A~200/5A | Φ=20mm | 1.5~5 | 0.5 /1.0 | 0.72KV(AC) |
| CA-62/30 | 30/5A~200/5A | Φ=30mm | 1.5~5 | 0.5 /1.0 | 0.72KV(AC) |
| CA-62/40 | 60/5A~300/5A | Φ=40mm | 2.5~5 | 0.5 /1.0 | 0.72KV(AC) |
| CA-74/50 | 300/5A~600/5A | Φ=50mm | 2.5~5 | 0.5/1.0 | 0.72KV(AC) |
| CA-80/30 | 30/5A~200/5A | Φ=30mm | 2.5~5 | 0.5 /1.0 | 0.72KV(AC) |
| CA-80/40 | 100/5A~500/5A | Φ=40mm | 2.5~10 | 0.5/1.0 | 0.72KV(AC) |
| CA-86/60 | 250/5A~1000/5A | Φ=60mm | 3.75~15 | 0.5/1.0 | 0.72KV(AC) |
| CA-100/60 | 400/5A~1600/5A | Φ=60mm | 3.75~20 | 0.5/1.0 | 0.72KV(AC) |
| CA-104/80 | 600/5A~2000/5A | Φ=80mm | 10~20 | 0.5/1.0 | 0.72KV(AC) |
| CA-140/100 | 800/5A~3000/5A | Φ=100mm | 15~25 | 0.5/1.0 | 0.72KV(AC) |
Product Overviews
Company Information
Everfar Electrical Co.,Ltd - Distinguished by OEM-manufacture, Develop customer's design and sells instruments for measurement ,such as Current Transformer, Panel meter, Shunt ,and Sourcing products. We ONLY produce the EXCELLENT QUALITY items with COMPETITIVE PRICE. We have been on the market since 2007 and we the joint venture by JSELE,QIANWEI,ZIP which are speicalized manufacturers of current transformer, Panel meter, Shunt at 2015.
Everfar Electrical Co.,Ltd know this instruments business very well, because of OEM for many biggest brand over the world, Our main oversea market is European, Africa, Asian, we export to over 50 countries and regions, such as the Italy, German, Poland, UK,Russia, Soth Africa, India, Singapore, etc. It is continue adding..
Everfar Electrical Co.,Ltd, has been qualified for ISO9001 and ISO140001, export more than 5 million pcs of products every year, and our customers help us to growing every year. We have about 100 workders to work focus on our customers speical requirements.
