Industrial waterproof SA1610 2 3 4 5 6 7 910 pin electric metal female connector weipu push pull ip67 4 pin waterproof connector

Share on:


Price:$3.85 - $4.40
Price in USD:Details

Quantity:


Product Overview

Description


Products Show
SA16 Series

SA series is IP67 connector made of anodized aluminium,especially designed for the high-end market,with push and pull coupling,It is one of our popular waterproof connectors.

The stunning aluminium made shell made it widely used in many high-end areas,such as medical devices,high-end equipments,testing or measuring equipments,communication fiel etc.It can be used for both data and power.

Please feel free to send message us, Our company will try our best to provide the best products and reasonable price for you. We serve for quality!!!!!!
\t
Product types
\t
Industrial waterproof SA1610 2 3 4 5 6 7 910 pin electric metal female connector weipu push pull ip67 4 pin waterproof connector
\t
Cable outer diameter range
\t
5mm-8mm
\t
Wire size
\t
0.785m㎡ / 18AWG
\t
Rated current
\t
 5A, 10A
\t
Rated voltage
\t
400V, 500V
\t
Contact resistance
\t
5mΩ, 2.5mΩ
\t
Insulation resistance
\t
2000mΩ
\t
IP rating
\t
IP67
