Pure Sine Wave Off Grid Hybrid Solar Inverter 48vdc 230vac Inverter 5kva 4kw 60A mppt charger
- Category: >>>
- Supplier: Shenzhen Sunray Power Co. Ltd.
Share on (62173327642):
Product Overview
Description
MPS Series 1KVA~5KVA Off Grid Solar Power Inverter MPPT Charger Pure SIne Wave
Model No. | MPS-1024M | MPS-3024M | MPS-5048M | MPS-5048M Plus | |||
Rated power | 1KVA/800W | 3000VA/2400W | 5000VA/4000W | 5000VA/5000W | |||
Input | voltage | 230VAC | |||||
selectable voltage range | 170-280VAC (for personal computers)/ 90-280VAC (for home appliances) | ||||||
Frequency range | 50Hz/60Hz (auto sensing) | ||||||
Output | AC voltage regulation (Batt.mode) | 230VAC±5% | |||||
Surge power | 2000VA | 6000VA | 10000VA | 10000VA | |||
efficiency (peak) | 90%-93% | 93% | |||||
transfer time | 10ms(for personal computers); 20ms (for home appliances) | ||||||
waveform | pure sine wave | ||||||
Battery& AC charger | battery voltage | 24VDC | 24VDC | 24VDC | 48VDC | ||
floating charge voltage | 27VD C | 27VDC | 27VDC | 54VDC | |||
overcharge protection | 31VDC | 31VDC | 31VDC | 60VDC | 60VDC | ||
maximum charge current(AC) | 10A/20A | 20A or 30A | 20A or 30A | 60A or 80A | 80A | ||
MAX PV array power | 600W | 600W | 1500W | 3000W or 4000W | 4000w | ||
MPPT range@ operating voltage | 30VDC-66VDC | 30VDC-66VDC | 60VDC-115VDC | 60VDC-115VDC | 60VDC-115VDC | ||
maximum PV array open circuit voltage | 75VDC | 75VDC | 145VDC | 145VDC | 145VDC | ||
maximum charging current | 25A | 25A | 60A | 60A | 60A | ||
maximum efficiency | 98% | ||||||
standby power consumpsion | 2W | ||||||
Physical | Dimension, D*W*H(mm) | 128*272*355 | |||||
Net weight (kgs) | 7.4 | 8 | 11 | 13.5 | 13.5 | ||
operating Environment | humidity | 5%-95% relative humidity ( non-condensing) | |||||
operating temperature | 0℃-55℃ | ||||||
storage temperature | -15℃-60℃ | ||||||
Specifications:
• Pure sine wave inverter
• Built-in MPPT solar charge controller
• Selectable input voltage range for home use
• Selectable charging current based on applications
• Configurable AC/Solar input priority via LCD setting
• Compatible to mains voltage or generator power
• Auto restart while AC is recovering
• Overload and short circuit protection
• Smart battery charger design for optimized battery performance
• Cold start function
• Parallel operation with up to 6 units only available for MPS 5K
