Magic price android tablet with thermal printer bill payment android pos terminal Gc096

Product Overview

Description

Magic price android tablet with thermal printer bill payment android pos terminal---Gc096

New Arrival  Windows based POS system with embedded  80mm printer 15.6+9 in

2. Prepaid Airtime: Electoronic prepaid card/PIN-LESS Top-up/Calling card

3. Bill payment: Electricity/Water/Gas/DTH/TV Recharges/Internet/Broadband/Insurance/Charity

4. E-ticketing: Railway/Ait/Bus/Movie,support various kinds of languages printing

5. Money Transfer: Deposit/Withdrawal/Remittanc

6. Loyalty Program: Loyalty card/Rewards card/Points card/Advantage card/Club card

7. Lottery: Lotto game/Bingo game/Casino game/

8. O2O Shipping

Products Description

















Specifications

Feature/Advantage	Self service table signboard electronic table ordering system with printer tablet POS terminal with printer
Casing/Material	Aluminum, ABS, PCBA, color: black and white
Platform	Application firmware, apps to be developed by customers
Operation System	Android 5.1 or higher
2D code decoding	with built-in 2D code decoding software, based on Android 5.1
CPU	RK3128 ARM Cortex-A7,quad core,1.2GHz(RK3288, A17 quad core, 1.8GHz optional)
Memory	DDR3 1GB (256*16 high speed cache chip, 2 pcs), 2GB optional
	Nandflash: EMMC 8GB,24bit ECC, 16GB optional
Operation display	G+G capacitive 5 point touch, scratch proof, harden
	10.1" RGB TFT panel,1024*600 pixel, Aspect ratio:16:9
Customer display	2.4 inch TFT screen, 320*240 pixel
Keypad	19 silicone rubber keys
ID card reader/NFC reader(Optional)	ID card or NFC reader, only support one, ID card module by security bureau
	NFC: 13.56MHZ contactless, meet standard of philips Mifare 1K/4K, ISO/IEC14443A/B, ISO/IEC15693,  Mifare DESfire, Sony Felica
Barcode scanning camera	2 mega pixel high definition, barcode reader only
Facial recognition camera	1.3 Mega pixel face recognition camera with light filling,
	wide dynamic binocular camera 2MP-8MP optional
Speaker	3W, 4Ω full frequency high effective speaker
Microphone	high sensitive compacitive mic
Commucation module	Wifi module: IEEE802.11b/g/n compatible with wapi(optional)
	Bluetooth:support 2.0+EDR, 3.0, 4.0
	Ethernet(RJ45), support TCP/IP HTTP protocols
	(Optional)external 4G dongle(specified module, can instal in the battery compartment)
Printer	High speed thermal printer, paper width: 58mm, printing speed: 3cm/s
	can print text, image, bar code with setting size and font
Antenna	Built-in high gain antenna
Multi-media function	High effient DSP processing, music,support mp3, wma and etc, support lyric display line by line or full display
	Video, support 4k,H.265, HDMI 2.0,video enhancemene
	Picture, jpeg, jpg, bmp, gif, jfif, support upto 8000*8000 pixel
External interface	USB x2
	PS/2 port x1
(may vary for different product batch,OEM available)	RJ11 x1,
	Ethernet RJ45 port, 1 pcs, support TCP/IP HTTP protocol
	Earphone port and microphone port 1 set
	DC in x1: 9V, 3V
Accessories	DC power adaptor,input 100-240V, output, 9V, 3A



Packaging &shipping





 1.Ship our products to our customers by the DHL,UPS,TNT,EMS and FedEx (door to door)

 2.Normally,it will take about 3-7 working days to ship the products,some remote places will need 1-3 working days more

 3.Will recommend the most fastest and safest shippemnt way for our customers









Our services



Pre-sale service:Will do our best to help customer to choose the suitable POS afer make sure the customer's detail requirements. The technical specifications will be sent for checking. All the inquiry and email will be responsed within 8 hours



In-sale service: Will provide the updated information of the shipment and payment.Will always let the customer to know the dated production information



After-sale service: Will provide one year warranty for all of our POS terminal.Will provide solution if found any broken devices after customer receive the goods. Will provide powerful technical for customers' secondary development. Will always provide repairing service



ODM service:ODM is available in  our factory. Will design the new products after make sure the detail requirements  of customers.





• Our Company



FAQ

 .



Q1. Can not Turn On
A: Check the power adapter, or try to change another workable power adapter.
Check the battery, or try to change another normal battery.
Remove the battery, and only connect the power adapter. Or only use battery, and do not connect power adapter to test it. Then check the Power Supply Circuit and switch on/off the circuit according the test result.
If the circuit has no problem, and it still can not turn on, please try to discharge.



Q2. Can not detect the SIM CARD
A: Please check whether the SIM card is installed well.
Install the SIM CARD again.
Change another SIM card
Scrape the surface of the metal spring in the SIM CARD slot with knife.
Check whether all the weld point of the SIM CARD slot is welded well or not.. If not, please weld it again.
Replace the part of the SIM CARD slot.



Q3. Can not detect wireless signal
A: Please check whether it has GSM wireless signal in this place. If it has no GSM wireless signal or the signal is very weak, please try to test the terminal in another place with good GSM wireless signal.
Otherwise, please open the shell of the device, and check if the antenna is connected well.



Q4. Print unconventionality
A: If it can’t print, or has other print problem, please check the problem device according to following steps:
(1). Open the shell of the POS.
(2). Clean the printer header with ethanol.
(3). Check the connector cable
(4). Disconnect the cable, and clean the connector of the cable
(5). Reinstall, and test it again.



Q5. Print blurred
A: If it prints out blurry receipt, please do following steps.
(1). Clean the print header
Maybe it has some carbon accumulation on the print header.
(2). Check whether the print header installed well or not
Open the cover of the POS. Dismantle the print header.
There are two spring button on the print header.



Q6:Cannot connect with the computer

If the Gc096 Windows/Android POS system  cannot connect with the computer by the OTG port,pls check whether you have installed the driver.



Q7: How can you provide the SDK

We will not provide application software but will provide the free development document for our customers' secondary development.Would appreciate it if you tell us your function module before place an

order,we will send the document according to your detail requirements



Q8: What is your warranty policy?



A:Will provide 12 months warranty after the shipment  for our normal  pos system terminals.For some designated modes, the warranty can be longer. During the warranty, the unworkable pos machines or parts can be repair or replace by free.Considering the high shipping cost in the international trade, we will send some spare parts and machines(1%~3%) in the normal order.



Q9: what is your sample policy?



A:Usually, customers should pay for the sample and the sample price will be a little higher than the normal order.We will retuarn the sample cost in the normal order if your quantity is large enough. We warmly welcome you to come to our factory to test the sample



Q10: How about your delivery?



A: Since we are professional manufacturer and even has our own SMT workshop. From R&D to shipment, all the processing can be controled by ourselves, so, delivery is not a problem for us
