Suitable for packaging of regular objects such as biscuits, cubes or round shapes, such as biscuits, rice crackers, snow cakes, egg yolk pies, chocolate, bread, instant noodles, moon cakes, boarded medicines, daily necessities, industrial parts, cartons, trays Wait.
Main performance and structural features
1) The whole machine has reasonable design, stable performance, PLC control and simple operation.
2) Double inverter control, the bag length can be set and cut, no need to adjust the air, one step in place, saving time and film.
3) Man-machine interface, parameter setting is convenient and quick.
4) With fault self-diagnosis function, the fault display is clear at a glance.
5) High-precision photoelectric tracking system, digital input sealing and cutting position, making the sealing and cutting position more accurate.
6) Temperature independent PID control, better suited to a variety of packaging materials.
7) Positioning stop function, no sticking knife, no waste of film.
8) The drive system is simple, the work is more reliable, and the maintenance is more convenient.
9) All controls are implemented by software, which is convenient for function adjustment and technical upgrade, and never lags behind.
Optional equipment
1) Ink printing and printing machine, can print 1 to many rows
2) Straight line
3) Reticulated end seal
4) Large touch screen
DC parameters
Type
Bag Length
Bag Width
Film width (mm)
Packing Speed
Product Height
Voltage Power
Weight
Size L*W*H (mm)
(mm)
(mm)
(Bag/min)
(mm)
(kg)
DC-250
120-280
30-110
Max.250
40-230
Max.55
220V/50/60Hz/2.4Kw
700
3770*670*1450
DC-350
130-450
40-160
Max.350
30-150
Max.75
220V/50/60Hz/2.6Kw
800
4020*745*1450
DC-450
130-450
50-180
Max.450
30-150
Max.75
220V/50/60Hz/2.6Kw
900
4020*800*1450
DC-600
300-600
180-280
Max.600
30-150
Max.75
220V/50/60Hz/2.6Kw
800
4020*770*1450
Packaging & Shipping
Machine packing inside is plastic films and outside is fumigation wooden case.Our wooden case is very strong,it can bear long time shipping on the sea.And machine with preservative film,it can stop the salt sea water enter into the machine and make the machine corrosion.
Packaging Details
1) The surface of the machine is stainless steel or paint protection.
2) sealed packaging will be wrapped in the machine.
3) Outer packaging is no fumigation wooden box
4) Port: Shanghai China
5) Lead Time :within 7-15 days
1) Upon receipt of payment , delivery date will be in 3-15days
2) By Air, by Sea or by Express (DHL etc)
3) Shipment cost will depend on the destination, shipment way,
size and the weight of the goods.
Company Information
1) Shanghai DiChuang Packaging Machinery Co., Ltd. is the backbone enterprise of the packaging industry in Shanghai. It specializes in the development, production and sales of packaging machinery. The company has strong technical force, stable product quality, and has a large number of professional technical personnel for packaging, which can be used to customize all kinds of non - standard packaging equipment.
2) The company's products are: full automatic, semi self packer, sealing machine, code printer, heat shrink packaging machine, continuous sealing machine, vacuum packaging machine, particle, powder, liquid, sauce packaging machine, pillow packing machine, filling and sealing machine and more than ten varieties.
3) Companies adhere to the "strategic thinking of everything for the purpose of" to the market, to become "the most outstanding Chinese professional packaging machinery manufacturers as the goal, is willing to improve its sales network and perfect customer service system, in the pursuit of win-win sincerity, with the same industry at home and abroad in close cooperation, sharing of resources, create brilliant!
Our advantages
1) Samples and our catalogue and other information are offered for free,once you place an order,
our staff would track your order in the whole process.
2) We will build permanent profile for every customer,and we provide consulting service for you.
3) One year quality warranty and free lifetime technique support ,whenever more information is
needed, please contact us .
4) We could adjust the formulas of our products in order to meet our customers’ satisfactory and
adapt to the local requirement.
5) Free spare parts would be supplied if machine broken within warranty period.
6) A warm welcome to visit our factory, we will be very happy to serve you.
Contact Us
Kindly Reminder:
Please let us know the follow packing details when you offer,so that we can check if this model is suitable for your case.Thank you in advance.
