Product Overview

Description

lda model motordriven overhead crane puentes grua

1.Single Beam Overhead Crane Description

lda model motordriven overhead crane puentes grua is widely used in plants,warehouses,material stocks to lift godds. It is prohibited to use the equipment in the combustiblle,explosive or corrosives enviroment.

The capacity:1-30ton

The span : 7.5-31.5m

The working grade : A3-A5

The working temperature:-25℃ to 40℃



Technical parameters of single girder overhead crane:



Mechanism			Item		Unit	Result
Item
Lifting capacity					ton	1-30ton
Working grade						A3-A5
Span					m	7.5-31.5m
Working environment temperture					°C	-25~40
Travelling mechanism		working speed			m/min	20-75
		motor	type			ZDY1 21-4	ZDR 100-4
			power		kw	2*0.8	2*1.5
			rotational speed		m/min	1380
Lifting mechanism		lifting speed			m/min	8/0.8(7/0.7)   3.5(3.5/0.35)    8(7)
		lifting height			H(m)	6  9  12  18  24  30
		travelling speed			m/min	20    30
working system					A3-A5
power source					three-phase 380V 50HZ





2.Single Beam Overhead Crane Details

lda model motordriven overhead crane puentes grua is improved and designed on the basis of LD model. It is characterized by more reasonable structure and higher strenght steel as a whole, Used together with CD  model, MD model electric hoist as a complete set.





Q. What's the information should I provide when inquiry?
More details or drawings, better.
Lift capacity ?

span ?

lift height  ?

power sourceor other specials you give us will be more appreciated ?

Q.What makes you different from other manufacturers ?

We believe our service department has the experience and knowledge to safely service your overhead cranes,gantry cranes,port crane and hoists .We have trained service technicians who will be able to get your material handling equipment up and running ,and have been providing our customer’s an effective service solution .
Q. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
Q. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
Q. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
Q:The space of my workshop is limited, can the crane ok for mine?

Thanks for your question. For low headroom workshop, we have the Special products. The detail dimension please consult our professional engineer.
