EMM078 High Speed CNC Digital Memory Pillow PU Foam Machine
- Category: >>>
- Supplier: Extreme Machinery Manufacture Co. Ltd. (Jingjiang)
Share on (62177217826):
Product Overview
Description
EMM078 High Speed CNC Digital Memory Pillow PU Foam Machine
Main parameters and descriptions for the equipment
| Type | EMM078-A20 |
| Suitable foaming system | soft foam, hard foam, simi-hard foam |
| Suitable material viscosity (22℃) | polyol : 2000mPa.s |
| isocyana:1000mPa.s | |
| Pouring output | 500~1500g/s (1:1), with ratio range adjustable 3:1~1:1 |
| Pouring program time | 0.5~99.99sec |
| Inject the quantity of the procedure | Manual inject: 9 |
| Automatic inject: 99 | |
| Hydraulic unit | hydraulic pump output: 23L/min |
| motor power: 7.5kw | |
| motor speed: 1450rpm | |
| oil tank volume: 8 |
1. Working pressure limit and control system
Both polyol and isocyanate side working pressure are allowed in a range of 6~22Mpa. Whenever the working pressure exceeds the range, the pouring operation will be stopped automatically and an alarm message of < working pressure abnormality > will be displaying on control panel at the same time.The limit pressure of the metering pump is pre-settled as 25Mpa and with mechanical & electrical safety protection:
Mechanical protection: the relief valve function open whenever pressure reach 25Mpa,
Electrical protection: the metering unit emergency stop, audio alarm, and a message of <pump
over pressure> display on panel screen.
The POLY. metering pump inlet pressure protection is pre-settled as 0.25Mpa, and the ISO. metering pump inlet pressure protection is pre-settled as 0.15Mpa. Whenever the inlet pressure lower than the preset value, the metering unit emergency stop, audio alarm, and a message of <pump pre-pressure too low> display on panel screen.
2. Components’ flow output control and testing units
Bases on the pump’s flowout and the components’ mixing inquery, set two parameters in the pouring course; the two metering units are drived by two independence motors , through change variable high-pressure displacement of the metering pump’s flow out to control the metering pump’s output.
3.Component filter:
Two components furnished with filter separately, and the filters’ precision is 330μm. Rotate the axle of the filter and fixed blowdown regularly. Out of the filter with digital pressure switch to protect the metering pump.
Our Services
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
Service during the Sale
1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.
2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.
3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
