Aoelec AUB1C 4.5kA din rail mounting mini circuit breaker/mcb
- Category: >>>
- Supplier: Wenzhou Aoelec Electrical Co. Ltd. [Zhejiang China]Wenzhou
Share on (62178254502):
Product Overview
Description
Function and Feature:
Protection against both overload and short circuit,function of isolation
High short circuit capacity
Contact position indicator
Pin/fork type busbar terminal connecting
35mm DIN rail mounting and screw mounting
Handle can be locked with pad-lock to prevent unwanted operation for safety.
Full range accessories are available.
Technical data
Rated current(In):1,2,3,4,6,10,13,16,20,25,32,40,45,50,63A
Rate voltage(Un):230/415VAC,400/415VAC
Breaking capacity:4.5kA
Rated frequency:50/60Hz
Tripping charateristics:B,C,D
Number of poles:1P,2P,3P,4P,1P+N,3P+N
Rated impulse withstand voltage(Uimp):4kv
Electrical endurance:10000cycles
Mechanical endurance:20000cycles
Terminal:pillar type
Cable termination:25mm2
Torque of screw:2.5Nm
IP degree:IP20
Standards:IEC/EN 60898-1
Catalog No. CTN Size:46.5X24X17.5
| In(A) | B(3-5In) | C(5-10In) | D(10-20In) | QTY/Box | QTY/CTN |
| Model No. | Model No. | Model No. | PCS | PCS | |
| 6A | AUB1C 1P B6 | AUB1C 1P C6 | AUB1C 1P D6 | 12 | 120 |
| 10A | AUB1C 1P B10 | AUB1C 1P C10 | AUB1C 1P D10 | 12 | 120 |
| 16A | AUB1C 1P B16 | AUB1C 1P C16 | AUB1C 1P D16 | 12 | 120 |
| 20A | AUB1C 1P B20 | AUB1C 1P C20 | AUB1C 1P D20 | 12 | 120 |
| 25A | AUB1C 1P B25 | AUB1C 1P C25 | AUB1C 1P D25 | 12 | 120 |
| 32A | AUB1C 1P B32 | AUB1C 1P C32 | AUB1C 1P D32 | 12 | 120 |
| 40A | AUB1C 1P B40 | AUB1C 1P C40 | AUB1C 1P D40 | 12 | 120 |
| 45A | AUB1C 1P B45 | AUB1C 1P C45 | AUB1C 1P D45 | 12 | 120 |
| 50A | AUB1C 1P B50 | AUB1C 1P C50 | AUB1C 1P D50 | 12 | 120 |
| 63A | AUB1C 1P B63 | AUB1C 1P C63 | AUB1C 1P D63 | 12 | 120 |
About us:
Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates
