Halar ECTFE powder 6014 6514 6614 6914

Product Overview

Description

ECTFE (Ethylene ChloroTriFluoroEthylene) specification
It was designed to provide chemical resistance in heavy duty corrosion applications. It is a partially fluorinated polymer (a fluoropolymer), semi-crystalline and can be processed in the melt. Chemically it is a copolymer of ethylene and chlorotrifluoroethylene.

Typical Properties

Property	Test Method	Units	Halar®  Melt Processable
Melting point, min.	ASTM D3418	°C	240-245
Specific gravity	ASTM D792	°C	1.68
Water absorption,  24h @ 23°C	ASTM D570	%	<0.1
Tensile stress  at yield @ 23°C	ASTM D638  50mm/mm	MPa	30-32
Tensile stress  at break @ 23°C	ASTM D638  50mm/mm	MPa	40-57
Tensile Modulus	ASTM D638   1mm/min	MPa	1,400-2,100
IZOD impact  notched V 10 mm @ 23°C	ASTM D256	J/m	no break
Taber abrasion resistance,  CS-17 wheel, 9.81 N load	ASTM D4060	mg/1000 rev	25-35
Friction coefficient, static/dynamic	ASTM D1894		0.1-0.2
Volume resistivity	ASTM D257	Ω.cm	10^16
Linear thermal expansion coefficient	ASTM D696	10-6/K	100
