R 1 agriculture tyre 14.9 24 Irrigation tyre with rim

Product Overview

Description





11.2-24 14.9-24 11.2-38 gricultural tyre

agricultural tyre sizes of R1 pattern:



AGRICULTURAL TYRE/TRACTOR TIRE  :



Pattern	Size	Ply	Overall Diameter (mm)	Section Width (mm)	Rim	Inflated Pressure
R-1	4.00-12	4	535	112	3.00D	240
R-1	5.00-12	6	590	145	4.00E	200
R-1	6.00-16	8	690	165	4.50E	250
R-1	6.50-16	8	765	180	4.50E	250
R-1	7.50-16	8	810	205	5.50F	210
R-1	7.50-20	8	910	205	5.50F	240
R-1	9.50-20	8	950	240	W8	210
R-1	8.3-24	8	995	210	W7	240
R-1	9.5-24	8	950	240	W8	210
R-1	11.2-24	8	1105	285	W10	240
R-1	11.2-28	8	1495	284	W10	120
R-1	12.4-24	8	1160	315	W11	230
R-1	12.4-28	8	1260	315	W11	230
R-1	13.6-24	8	1210	345	W12	200
R-1	13.6-28	8	1310	345	W12	200
R-1	14.9-24	8	1265	378	W13	180
R-1	14.9-28	8	1365	378	W13	230
R-1	16.9-28	8	1435	430	W15L	200
R-1	16.9-30	8	1485	430	W15L	200
R-1	16.9-34	10	1585	430	W15L	200
R-1	11.2-38	8	1459	284	10	120
R-1	18.4-30	10	1550	467	W16L	180
R-1	18.4-34	10	1688	457	W16L	180
R-1	15.5-38	10	1570	395	DW14	230
R-1	18.4-38	10	1755	467	W16L	210
R-1	20.8-38	10	1835	528	W18L	270













AGRICULTURAL TYRE/TRACTOR TIRE 11.2-24

1 Wrapped with plastic belt or as customers mind.

2.Delivery time:with in 15-20 days after received deposit.

3 Payment term:T/T30% as deposit and 70% balance should be paid before shipment.





Why choose Qingdao Huifuxin Tyre Co,.Ltd?

1. experience export all over the world.

2. fast delivery, best service

3. good pattern research development.

4. OEM acceptable
