DP 350R all in one total heat recovery fresh air purifying dehumidifying ventilation
- Category: >>>
- Supplier: Okonoff Science & Technology (Shanghai) Co. Ltd
Share on (62183146209):
Product Overview
Description
 | DP-350r ceiling flush mounted ventilation is a all-in-one total heat recovery machine. It can supply fresh air, furify air, dehumidify air. Be widely used in residence, business building, school, hospital, factory, etc. |
Feature:
Ultra slim design
Ultra silent
High efficiency purification and dehumidification
Environmental protection refrigerant
Double sides repair door
Automatic drainage
CFD optimization design
Heat exchange
Cooling system modularization
Built-in drain pump, level ruler
Technical parameter:
|
| DP250R | DP350R |
|
Dehumidify Capacity | [L/D] | 22 | 30 |
|
Air Volume | [m3/h] | 250 | 350 |
|
Fresh Air | [m3/h)] | 200 | 300 |
|
Static Pressure | [Pa] | 90 | 90 |
|
Voltage | [V-50Hz] | 220 | 220 |
|
Power | [kw] | 0.45 | 0.65 |
|
Compressor | type | Totally enclosed rotation compressor | ||
Cryogen | Refrigerant | R134A | R407C |
|
Control type | Capillary | |||
Evaporator |
| High efficiency purple copper tube aluminum sheet | ||
Fan | type | High efficiency EC fan | ||
Heat recovery | type | Total heat exchanger | ||
Filter | type | PM2.5 high efficiency filter | ||
Temperature exchange efficiency | Heat[%] | 67 | ||
Refrigerate[%] | 76 | |||
Enthalpy exchange efficiency | Heat[%] | 55 | ||
Refrigerate[%] | 63 | |||
Air outlet | [mm] | Ø147 | ||
Size (LxWxH) | [mm] | 1150x730x270 | 1150x730x270 |
|
Weight | [kg] | 65 | 70 |
|
