Book ink color fastness testing machine Ink Abrasion Tester Color fastness test of fabric
- Category: >>>
- Supplier: Hangzhou Yante Science And Technology Co. Ltd.
Share on (62183379094):
Product Overview
Description
Product Overview
Ink Abrasion Tester is specialized in testing the abrasion resistance of printing ink layer, the abrasion resistance of PS plate photosensitive layer and the abrasion resistance of the surface coating of related products; it can effectively analyze the poor abrasion resistance of printed matter, the ink layer peeling off, and the resistance of PS plate. Problems such as low SCPG and poor coating hardness of other products.
Details Images
Application Range
Resistance of printing ink layer
Product Feature
LCD English display, 4 speeds adjustable.
Power-off memory function, after power-on again, the state of the parameters entered before the last power-off will be maintained.
Closed-loop servo stepper motor, ball screw, precision dual optical axis guide.
Power-off memory function, after power-on again, the state of the parameters entered before the last power-off will be maintained.
Closed-loop servo stepper motor, ball screw, precision dual optical axis guide.
Execute Standard
GB/T 7706，GB/T 17497.3
Sales And Service Network
Product Paramenters
No. | Parameter item | Technical index |
1 | Power Supply | AC（220±10％）V, 50Hz 50W |
2 | Working Environment | Temperature(10~35)℃, Humidity≤ 85％ |
3 | Measuring range | （1～99999）times |
4 | Friction distance | 60mm |
5 | Friction speed | 21/43/85/106 (Times/min) |
6 | Load | 20N or 4pound |
7 | Dimension | 290×295×335 mm |
8 | Net Weight | 22kg around |
