2KW load power demand; standard configuration; system voltage DC48V
Configuration
No.
Product name
Specification
No.s
Note:
1
Solar panel
POLY-280W
4
2 series connection* 2 parallel
2
Bracket
C-type Steel
1
Hot tip galvanized
3
Inverter&Controller integrated cabinet with battery pack
FUWEI48V-2KW/20A
1
1, 20A PWM controller built-in
2,Power frequency sine wave output
3, Grid/Diesel input supported
4
Gel battery
12V-120AH
4
Daily discharge:4kWh;4 in series connection
5
Connector
MC4
2pairs
7
Power strip
2.5KW
1
All-powerful
Note:
1. The system can support a 2KW load for 4 hours in rainy day.
2. The maximum load power should not exceed 2KW (including inductive load starting shock, such as refrigerator, air conditioner, washing machine, etc. with conductive load)
3. Under standard lighting conditions, the battery can be filled for about 8 hours.
4. It is recommended that the daily power consumption be 2KWH per day.
5. If more than offered cable length, Extra charge for additional length
