K series IP68 waterproof 2K 12pin circular metal push pull connector HGG.2K.312.CLL

RM-HGG-2KC-312KS=HGG.2K.312.CLL
Explanation :  HGG: panle fixed socket, 2K : 2K size of outer shell,    C: natural-chrome plated , 312: 12 contacts. KS: female contact in solder; CIRCULAR CONNECTOR IN PUSH PULL TYPE

Main Features :
1. Security of the push-pull self-latching system.
2. 100% compatible with original connectors;
3. Multipole from  2 to 32pin contacts available
4. Key option: 1 key(G) & 2 key with different degree:30°,45°,60°,90°,...145°
5. 360°screening for full EMC shielding.
6. High packing density for space savings

7. Cable assembly as customers real needs (OEM is available)
8. Certification: CE, ROHS, Reach, SIO9001,SGS

9. Fast delivery ( 3-15 working days )

Compatible   B series, waterproof K series, half-moon S/E series, plastic P series connectors
Compatible FISCHERS 102 103 1031 104 105 series connectors
Compatible HIROSES HR10A series connectors
Compatible Binders M16 682 420 678 series connectors
Compatible FISCHERS Ultimate series UP01 UR01 UR02 connector
Substitue  W series deepsea waterproof RM-V series

Compatible ODUS metal L series and plastic M series connector
Cable assembly can be designed according customer real needs.

Accept OEM/ODM

Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Module Power, Sensor, Sensor Systems Instrumentation, Analysis Application.

• Focus on manufacturing & exporting metal and plastic circular connectors, cable assembly.
• Can be 100% compatible with original LEM. FISCHERS • ODUS • HIROSES • BINDERS •Military 38999
• Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16,RM-U,RM-V BNC, B680,B423 , 38999, 26482
• OEM are acceptable
• CO, Form A, Form E for customer clearance
• CE, ROHS, ISO:90001, SGS Audited manufacturer
• All the items can work normally after 5000 times mating
With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solution to meet customer's real needs in his field.
