P5 High Definition Thin And Light Unilumin LED Display With Store
- Category: >>>
- Supplier: Shenzhen Ledful Electronics Company Limited
Share on (62186748151):
Product Overview
Description
Product Description
Product Paramenters
Model | IF2 | IF2.5 | IF2.6 | IF2.9 | IF3 | IF3.9 | IF4 | IF4.8 | |||||||
Pixel Pitch(mm) | |||||||||||||||
Pixel Matrix Per Sq.m | 250,000 | 160,000 | 147,470 | 112,607 | 111,111 | 65,475 | 62,500 | 43,224 | |||||||
Pixel Configuration | SMD1515 | SMD1515/ SMD2121 | SMD1515 | SMD2121 | SMD2121 | SMD2121 | SMD2121 | SMD2121 | |||||||
Brightness (cd/Sq.m) | 900 | 900 | 900 | 900 | 900 | 900 | 1200 | 900 | |||||||
Scan | 1/40 | 1/32 | 1/32 | 1/16 | 1/32 | 1/16 | 1/16 | 1/16 | |||||||
Module Dimension (mm) | 320x160 / 256x128 | 320x160 | 250x250 | 250x250 | 192x192 | 250x250 | 320x160 / 256x128 | 250x250 | |||||||
Power Consumption (Max / Avg) | 720/ 240W/Sq.m | 710/ 230W/Sq.m | 700/ 220W/Sq.m | 690/ 210W/Sq.m | 690/ 210W/Sq.m | 520/ 200W/Sq.m | 500/ 180W/Sq.m | 480/ 160W/Sq.m | |||||||
Cabinet Dimension | 960x960mm / Customizable | ||||||||||||||
Cabinet Material | Iron | ||||||||||||||
Cabinet Weight | 32KG | ||||||||||||||
Service Access | Front / Rear | ||||||||||||||
Refresh Rate (HZ) | ≥1920 | ||||||||||||||
Grey Scale (bit) | 16 | ||||||||||||||
Viewing Angle (H/V) | 140°/140° | ||||||||||||||
IP Rate | IP43 | ||||||||||||||
Operation Temperature | -20ºC ~ +60ºC | ||||||||||||||
Input Voltage (AC) | 110V / 220V | ||||||||||||||
