Зажимной патрон LL 1

Brand:NTH

It‘’s a PUSH type collet are used mainly on turning ,CNC,special purpose machines and other,etc.
High clamping accuracy,high speed and construction of high rigidty.
The installation is the same as" Thru-hole power chuck"and they are replaceable with each other,No need to change the "Draw tube".
Sealed against swarf,chips and coolant.

The collet used must accord with DIN 6343
