90w Sunpower solar panel for the travel of RV boat coming mobile power from the sun yes you need
- Category: >>>
- Supplier: Shenzhen Ahony Power Co. Ltd.
Share on (62194576869):
Product Overview
Description
Product Description
Model No. | eGo S90w of solar panel for the travel of RV boat coming mobile power from the sun yes you need |
| Maximum Power[Wp] | 90 |
| Product Name | Semi-Flexible Solar Panel |
| Solar Cell | Back Contact Cell |
| Cell Array[Pcs] | 4*7 |
| Cell Efficiency | 22.60% |
| Size[mm] | 540x940x3 |
| Max Power Voltage Vmp[V] | 18.56 |
| Max Power Current Imp[A] | 4.85 |
| Open Circuit Voltage Voc[V] | 21.90 |
| Short Circuit Current Isc[A] | 5.24 |
| Net.Weight[kg] | 1.5 |
| Power tolerance[%] | ±5% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -1.74mV |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 100 V |
| Maximum Reverse Current[V] | 10A |
| Certification | CE ROHS |
| Surface/Backsheet | Japan ETFE/white plastic |
| Maximum bend radius(θ) | 30° |
| Cables and Connectors | PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC 4 connector |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Other notes | round corner R10,with eyelets |
| Package | 1pcs/Polyethylene foam(EPE Foam),then in 1 carton box |
