new design 2.54mm pin header smt straight type connector for pcb
- Category: >>>
- Supplier: Dongguan KAWEEI Electronic Co. Ltd.
Share on (62196703238):
Product Overview
Description
PRODUCTION
|
Product Name |
2.54mm pitch pin header |
|
Color - Resin |
Black |
|
Plating - Terminal |
Gold flash on contact |
|
Material - Plating Mating |
Tin plated on other area |
|
Material - Housing |
PBT/NY6T UL94V-0 Black |
|
Temperature Range - Operating |
-55°C to +105°C |
|
Electrical |
|
|
Current - Maximum |
3 Amp |
|
Voltage - Maximum |
500V AC/DC |
|
Contact resistance: |
25m Ohm Max |
|
Insulator resistance: |
5000M ohm min. |
|
Withstanding Voltage: |
1000V AC/Minute |
|
1.2.54mm pin header |
|
2.ROHS,REACH,ISO 9001:2008 |
|
3.manufacturing experience:10 years |
|
4.100% teste |
|
EXPEND USE: |
|
Mobile phones,digital camera,MP3,MP4,Medical,Automotive and aerospace fields. |
|
Physical |
|
| Product Name | Connector |
| Color - Resin | Natural |
| Plating - Terminal | Phosphor Bronze |
| Material - Plating Mating | Tin,Matte Tin or Gold plating over Nickel |
| Material - Housing | LCP UL94V-0 Black |
| Temperature Range - Operating | -25°C to +85°C |
| Electrical | |
| Current - Maximum | 0.5 Amp |
| Voltage - Maximum | 50V AC/DC |
| Contact resistance: | 40m Ohm Max |
| Insulator resistance: | 800M ohm min. |
| Withstanding Voltage: | 200V AC/Minute |
| Detail: | |
| Product name | Connectors |
| Certification | ISO9001,ROHS and the latest REACH |
| Handling Time(Lead time) | 2~4WKS (according to different products) |
| Sample | Mostly Free,Except the special items) |
| Minimum Order Quantity (MOQ) | 500 PCS |
| Delivery Terms | EXW,FOB Shenzhen or FOB Hong Kong |
| Payment Terms | Paypal,T/T in advance. If the amount is more than 5000USD,we can do 30% deposit before production,70% before shipment. |
| Application: | Mobile phones,digital camera,MP3,MP4,Medical,Automotive and aerospace fields. |
| Service: | ODM/OEM |
According to the different products to choose different packing way. Tube packing & Tape and Reel packing & Bag packing & Tray packing and other customized packing.
Shipping: UPS & DHL & FedEx & TNT and other Customer customized shipping way.
