In India high demand products fixed freight lifts automobile car elevator
- Category: Elevators >>>
- Supplier: Lingzhi Elevator Co. Ltd.
Share on (62197961071):
Product Overview
Description
Product Description
Effective car transport nanny
Ceiling: Paint Steel
Car wall/Car door: Paint steel
Illumination: Energy-saving light
Door Opening Mode: Side opening
C.O.P: stainless steel hairline panel
Flooring: Checkered plate
Sill: Cast iron
Double operation panels
The elevator car has two operation boxes. Therefore the driver can operate the elevator without stepping out of his/her beloved car.
Signal display system
Special signal display system is convenient for both inside and outside drivers.
Opposite door configuration
The elevator car has front and rear opening. It is more convenient for the car to enter into/exit from the elevator car. And it is more secure too.
Products Specifications
| Load(kg) | Speed(m/s) | Door opening type | Net door opening(mm) | Exterior size of car(mm) | Hoistway net size(mm) | Machine room net size(mm) | ||
| 3000 | 0.25/0.5 | Four panel center opening | 2400*2200 | 2700*5800 | Size(mm) | Pit depth | Top floor height | 4100*6160*2500 |
| 5000 | 0.25/0.5 | Four panel center opening | 2600*2200 | 3500*7200 | 4100*6160 | 1600 | 4800 | 4750*7560*2500 |
Note: only for reference, final manufactures please follow contract.
| · with/without drive operation | · Door closing time auto delaying |
| · Automatic return to the base landing | · False-call canceling |
| · Automatic landing | · Emergency Light |
| · Call cancel when begin reverse-running | · Driven over current protection |
| · Cage door opening when elevator arrives the floor where there is a hall call | · Door opening / closing time-limited protection |
| · Door opening / closing call indication | · Rope sliding protection |
| · Indication in the cage when hall calling | · Door Nudging |
| · Self-Learning of shaft data | · Trouble self-diagnosis and memory |
| · Full load non-stop operation | · Over speed falling protection |
| · Overload alarm, Car Operating panel display: “OL” | · Top/Bottom landing overpass protection |
| · Alarming device | · Inspection Operation |
| · In-car and m/r inter talk device | · Floor display |
| · Light and fan auto-control | · Light curtain protection with mechanical safety edge |
| · Elevator Locking Device | · Fireman’s return switch |
Company Information
Packaging & Shipping
FAQ
Q1. Your strengths?
A1: our factory has been established for many years, and we have experienced professional technology, production and sales team.
Q2. How can I get your offer?
A2: please send us an inquiry from alibaba and we will reply to you within 24 hours. We would appreciate it if you could provide us with all the elevator details so that you can get our quotation as soon as possible.
Q3. How to install and maintain the elevator?
A3: we can send engineers to your country (at the customer's expense) to guide the installation and then train workers for future maintenance. But in most cases, local workers can do this work through our guidance and technical support, or you can ask the local professional elevator engineers to do this work, which can save a lot of money for our customers. Of course, you can always get the support of our factory.
