High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management
High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management

High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management

Share on (62202060576):


Price:$2.50

Quantity:


Product Overview

Description



High Density Ultrathin 24 core Fiber Optic Splice Tray with Cable Management




Description
1. high density splice trey , ultrothin , 6mm thickness
2. with cable management function, save space , 1U max can load 24 splice *4 layers
3. with cable management mark
4. flexible to assemble to different pannel


Features
 1. Compared with the previous melting disc height is reduced, more compact.
2. Maximum expansion to 96 cores for 1U






Size
245 x 117 x 6 mm
Cover
transparant
Material
flame retardant or non-flame retardant
Maximum size
24 core
Operating temperature
-5℃~40℃
Relative humidity
≤85% (30℃)
Atmospheric pressure
70~106Kpa
Nominal operating wavelengths
850nm, 1310nm, 1550nm
Return loss
PC≥40dB, UPC≥50dB, APC≥60dB
Electrical strength
≥3KV(DC)/1min
