Sliding Saw machine is mainly used for cutting sheets into sized parts.It is easy to cut plywood and melamine sheets into cabinet components.Our sliding table saw is applied to processing all kinds of density boards, shaving boards, wood-based panels, ABS panels, PVC panels, solid wood and others wood.
Dimension of Sliding Table
3000*325*375mm
Max.Cutting Length
3000mm
Max.Cutting Width
1250mm
Max.Cutting Height
80mm
Speed of Scoring Saw Shaft
7000-8000r/min
Main Saw Blade Diameter
300mm/30mm
Scoring Saw Blade Diameter
120mm/20mm
Speed of Main Saw Shaft
4000-6000r/min
Scoring Saw Shaft Diameter
30mm
Motor Power
4KW+0.75KW
Voltage
380V or as your request
Tilting Saw Blade
90°
Overall Dimensions
3000*1100*1200mm
Gross Weight
650kg
Main Features
Hot sale automatic precision sliding table saw
Woodworking Use Slide Table Panel Saw,
We also accept customizaton. Include the outlook of the machine.
The motor is can be changed to 5.5kw. It will be more powerful.
Detailed Images
We've produced many types of sliding table saw.Basically,we have three series. They are F series,H series and S series.S series is high-end, so the price is high.
The configuration of each series is the same.The difference is dimensions of sliding table.The dimensions are 1.6M, 2.8m,3.0m and 3.2m.
And other difference is 90 degree or 45 degree.90 degree can only cut right Angle, 45 degree saw blade can be vertical, can also tilt, cut the hypotenuse.
The machine can be used for cutting all kinds of solid wood, density board, particle board, artificial board, ABS board, PVC board, organic glass panel and other wood structure and hardness similar to wood.
Certifications
Our Service
We now realizes a one-stop service system including processing, production, installation, storage, sales and after-sale service. Trade processing:Actively solving problems during manufacturing and delivery. After-sale service: We offer vedio available to service machinery overseas under merchandiser's supervision and translation. With a professional sale and technique group, we can assure you a considerate and professional service experience.
