Factory hot sale cable CATV amplifier Two way 2 outputs with best quality
- Category: >>>
- Supplier: SHENZHEN WOLCK NETWORK PRODUCT CO. LIMITED
Share on (62203608084):
Product Overview
Description
Hot Sale Outdoor 2 Output Power Catv Line Amplifier Rf Amplifier
VA-860S1 use for CATV system cable transmitting network, compensate cable transmitting for RF-signal loss, extend the transmitting of RF-signal or improve users distribution network. Amplifier use professional module amplify design, signal level adjustment, take convenience for network return and system adjustment. With embranchment output and two way distribution output, ensure widely practicability.
(1) Frequency range: 45~550/750/862MHz.
(2) EQ range: 0~-20dB adjust continuely.
(3) Gain range: 0-~20dB ajust continuely.
(4) Output mode1 way coupler or 2 splitter.
(5) Power supply: AC60V or AC220V.
(6) Over-current protection and lightning-proof.
(2) EQ range: 0~-20dB adjust continuely.
(3) Gain range: 0-~20dB ajust continuely.
(4) Output mode1 way coupler or 2 splitter.
(5) Power supply: AC60V or AC220V.
(6) Over-current protection and lightning-proof.
Technical Support
Packaging
Item | Parameter | Item | Parameter | ||||
VA-860S1 | VA-860S2 | VA-860S1 | VA-860S2 | ||||
Freguency range | 45~550/750 / 860MHz | EQ Adjustment | 0~20dB adjustable | ||||
Flatness in band | ≤± 0.75dB | IN/Out Impedance | 75 | ||||
Return loss | ≥ 16@87~550MHz ≥ 14@550~862MHz | Output Level | ≥110dBuv | ≥118dBuv | |||
Nominal working gain | 32dB | 40dB | Signal | 1% | 1.2% | ||
C/CSO | 60dB | 60dB | Power Supply | 60V or 220V/AC | |||
C/CTB | 61dB | 61dB | Current | 6A/AC 60V/AC | |||
Noise figure | 9dB | 9dB | RF Connector Type | F- connector | |||
ATT Adjustment | 0~20dB adjustable | Power Consumption | 12W (Max) | ||||
Shenzhen Wolck Network Porducts Co.,Ltd. is located in Shenzhen city which is one of the first-tier cities in China. Wolck company is a high-tech enterprise specializing in the development of technology and equipment for EPON/GPON/CATV equipments.Production and equipments detailed can be shown online, and all products will be passed the test before shipment.
Wolck company not only offer equipments but also offer technical support and best service for after-sales. Wolck company also is Quality Guarantee Enterprise, got the ISO9000 cetificate, and offer cetificates such as CE, CO, FORM-E/F/M etc.
