Rotary axis A axis 4th axis tailstock for CNC router dividing head three-dimensional sculpture take 80 fix with 4 chuck

Packing list:

1 x A axis with 4 jaw chuck

1 x Tailstock

Model Number: 57-80-4

Stepper motor: 57 step motor current 3A

Chuck: 80MM 4-jawchuck
Center height: 70MM

Total height:110mm

Mounting hole: 80 mm,

M8 screw
worm reducer

Speed reducing ratio: 20:1

Weight: 12KG

----------------------------------------------------------------------------------------------------------------------------------

Model Number: 57-100-4

Stepper motor: 57 step motor current 3A

Chuck: 100MM 4-jaw chuck
Center height: 70MM

Total height:120mm
Mounting hole: 80 mm,

M8 screw
worm reducer

Speed reducing ratio: 20:1

Weight: 13KG

----------------------------------------------------------------------------------------------------------------------------------

Model Number: 86-130-4

Stepper motor: 86 step motor current 4.2A

Chuck: 130MM 4-jawchuck
Center height: 92MM

Total height:150mm
Mounting hole: 80 mm,

M8 screw
worm reducer

Speed reducing ratio: 20:1

Weight: 15KG

Fourth axis pulse setting:

Mach3 system settings: 1 degree required pulse number

(1 circle drive motor pulse number of fine fraction) 83019 perimeter

For example, two phase motor, fine fraction 8, reduction ratio 20:1

1 set according to the angle

32000 / 360 (degrees) =88.88888888 (pulse number)

2 setting the length of the graph or the circumference of a graph

32000 83019 (length 125.6 mm) =254.777 (pulse number)
