Product Overview

Description

–  WELCOME TO ANDEA CUSTOM DOOR  –  Hello, we are door and door opener factory in Guangdong, China. Our products include hospital operation room door, clean room door, x-ray proof door/window, steel fire proof door, fire proof roller shutter door/window, automatic/manual roller shutter door (aluminum/steel/pvc), sectional garage door (steel/aluminum+glass), and entrance guard systems (opener, motor, etc). Welcome to contact us if any need.





















2, Function: X-Ray protection.

3, Necessary protection doors for CT room, X Ray room, ICU, research laboratory, factory flaw detection                  workshop, etc.

4,  Andea lead-lined X-ray protection doors with excellent radiation protection performance, reasonable  &                 strong door structure, smooth door opening/closing, novel and elegant appearance, as well as perfect match       between visual effect and high-quality medical equipment.

5,  Andea lead lined X-ray protection door is an ideal quality product applicable to radiology rooms for such                equipment as linear accelerators, Gamma knifes, Post-loading equipment, Cobalt-60, PET-CT, CT, DR,                DSA, and X-ray machines in modern high-grade hospitals and laboratory.



6, Door panel construction

1)  Door skin: 0.8mm cold rolled steel/0.8mm stainless steel/1.2mm aluminum plate/HPL board

2)  MDF/plywood board: 5mm thickness high quality MDF

3)  Steel structure: 1.8mm thickness, 30mmX30mm galvanized steel tube structure + 30mm PU foam/fire rated cotton

4)  Lead sheet: 1mm--3mm lead sheet for each side (2mm to 6mm lead sheet total)



7, Thickness of door leaf:

    Usual: 42mm--50mm  (different lead sheet thickness)



8, Door skin material:

1)  1.0mm thickness full stainless steel sheets

2)   0.8mm thickness cold-rolled steel plate with color painted

      Usual color: light blue, offwhite, white, red, beige, etc.

3)  HPL board

      Usual color: white/blue/pink/beige/woodlike, etc.



9,  Lead sheet thickness: 2mm, 3mm, 4mm, 6mm

10, Door frame: 1.2mm thickness stainless steel or color painted steel



11, Opening type

      Sliding door, usually with electric control sliding door system, with feet sensor switch/hand sensor switch.            Also can be manual opening with handle.

      Swing door, with automatic swing door operator+handle/manually door closer+lock.



12, Hinges/locks: stainless steel



13, Usual door size: (unusual size need 3 more days producing)



       Sliding door:  1200X2250mm (wall to wall size should less than 900X2100)

                            1500X2250mm (wall to wall size should less than 1200X2100)

                            1800X2250mm (wall to wall size should less than 1500X2100)



      Swing door:   800X2100mm, single door, with frame size

                            900X2100mm, single door, with frame size

                            1200X2100mm, mother & son door, (300+900)X2100with frame size

                            1500X2100mm, double door, with frame size



Also have radiation protection glass window

Material: radiation protection glass, ZF3 standard medical lead glass

Lead glass thickness: 8mm, 10mm, 12mm, 15mm, 18mm, 20mm

Visual window frame material: 1.2mm stainless steel/color coated steel

                                                 + 2mm-4mm lead sheet lined







Hospital X-ray Protection Door Technical Specifications



Lead sheet thickness		1mm, 2mm, 3mm, 4mm, 6mm
Lead glass thickness		8mm,12mm,15mm,18mm, 20mm
Door skin material		color painted steel, stainless steel (SUS), aluminum, PVC, fireproof board, etc.
Door frame material		stainless steel
Knock blade material		stainless steel
Seal material		silica gel, rubber
Door lock & door hinge material		stainless steel
Door size	swing door	single door width: 700mm-1000mm, mother & son door width: 1200mm-1400mm, double door width: 1400mm-1800mm, door height: 1900mm-3000mm
	sliding door	single door width: 1000mm-2200mm, double door width: 1500mm-3000mm, door height: 1900mm-3100mm
Door skin color		original SUS color, original aluminum color, light blue, white, grey, beige, etc.
Automatic door system		opening door by hand sensor switch, feet sensor switch or press switch
Door advantage		airtight, X-ray protection
Optional accessories		1, LED light screen 2, visual window 3, bottom sinking down seals





∗ Please kindly note that this product is customized, and the price is only for your reference. If need exact price,          please contact us before starting order. After confirming the size and your requirements, we will offer the exact          quotation.





    Yes, we are door factory with 10+ years experience in designing and producing door products which include

    1) Door and window

      A. door for hospital: operating room door, swing hermetic door, X-ray proof door, MRI door, HPL door;

      B. door for clean room: swing clean room door, sliding clean room door, PVC fast rolling door, PVC                          door/window, aluminum door/window, steel door/window (60min fire rated);

      C. door for factory: roller shutter, PVC fast rolling door, industrial sectional door, fire rated door, steel gate;

      D. door for commercial building & house: automatic sliding glass door, manual glass door&window, security             window grill, aluminum roller shutter, grill/PVC roller shutter, sectional garage door, glass garage door;

     2) Automatic door opener

     A. sliding glass door opener, swing room door opener;

     B. sliding metal gate motor, swing metal gate motor;

     C. rolling shutter door opener, sectional garage door opener, tubular motor;

     3) Others:

     A. automatic door system: ID card, ID card reader, finger print reader, magnetic lock, power supply box,                   wireless switch;

     B. raw material for x-ray proof door: lead sheet, copper sheet, BaSo4 sand, lead glass;

     C. medical instrument cabinet and medical cart.

2. Do you customize door/window?

Yes, we do. Send us details such as size, technical drawing etc. E-catalogue and pricelist will be supplied.

3. What is your lead time?

 5-7 days for door opener, 7-12 days for most of our door/window, 15-20 days for X-ray protection door, 25-30

 days for mass production after receipt of deposit.

4. What is the shipping port? Huangpu seaport in Guangzhou, Yantian and Shekou seaports in Shenzhen.

5. What is your MOQ? Door opener: 1 set; Door: 1 set.

6. What is your terms of payment? We accept 50% T/T in advance, 50% T/T before shipment.



Key Words

radiation protection door, xray proof doors, automatic lead door, custom door, factory direct sale

sliding or swing



Made in Guangzhou, China
