batch type peanut bean apricot almond dryer drying machine

batch type peanut bean apricot almond dryer drying machine

1.Principle:

-The CT-C support to use steam,electric,gas or oil as heating source.the laminar air flow passes through the drying trays and carry out the heat transmission to drying raw material.fresh air is introduced,hot damp air is discharged continuously as the same time.in this way,appropriate RH in dryer can be maintained.the ultimate advantage of dryer is that hot air is re-cycled inside.it increaseds heat transmission and save energy.it makes heat efficiency of dryer raise from 3-8% of tranditional drying oven up to about 35-40%.the dryer adopt reinforced ventilation to decrease temperature difference.user can adjust air distributor in order to make the temperature differenece at the best state

-CT-C tray dryer adopt low noise high temperature resistant axial fan and also equips with automatic constant temperature control system,computer control system for customers choice.

-Explanation

-There are four kinds of heating source for choice:steam,electricity,heat oil,both steam and electricity.

-The temperature(steam heating):50-150 degree

-The temperature(when using electricity and far-infrared):50-350 degree

-The automiatic control system or the computer control system is selectable.

-commonly used steam pressure 0.2-0.8MPa(2-8kg/cm2).

-Standard electric heating is 15kw for type CT-1,CT-T-1,easu flammable and explosive material is forbidden.

-The special requirements should be indicated at the time of order.

-If the operation temperature is more than 140 degree or less than 60 degree it shoud be indicated at the time of order.

-The oven and baking tray made by our factory are uniform in the dimensions,and can be exchanged with each other.

-Drying tray dimensions:460*640*45mm

-Explosive-proof motor and control cabinet as option.

Pre-service

Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.

1. Introduce the product to the customer in detail, answer the question raised by customer carefully;

2.Make plans for choice according to the needs and special requirements of users in different sectors;

Sale service

1. Ensure product with high quality and pre-commissioning before delivery;

2. Delivery on time;

3.Provide full set of documents meet customer’s requirements.

After-sale service

Provide considerate services to minimize clients’ worries.

1.Assist clients to prepare for the first construction scheme;

2.Install and debug the equipment;

3.Train the first-line operators;

4. Examine the equipment;

5.Take initiative to eliminate the troubles rapidly;

6.Provide technical support;

7.Establish long-term and friendly relationship.

Service commitment

1. Provide clients one-year warranty to make sure the machine work well;

2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely
