FIREWOOD PROCESSOR log splitter WITH BIGGER BLADE SAW
US $1243-$1354
Wood Branches/Bamboo Wood Chipper Shredders
- Category: Forestry Machinery >>>
- Supplier: Yantai,Rima,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Model | BX42 | BX62 | BX62R | BX92R |
Max Chipping Diameter | 100mm/ 4'' | 150mm/6’’ | 150mm/ 6'' | 250mm/10'' |
Chipping House Opening | 4''x10'' | 6.5’’x12’’ | 6.5''x12'' | 10''x15'' |
No. of Blades | 4 | 4 | 4 | 4 |
Rotor Size | 25'' | 30’’ | 30'' | 36'' |
Feeding System Feed | Self Feed | Self Feed | Hydraulic Feed | Hydraulic Feed |
Hopper Hold | 40''Lx42''Wx60''H | 50’’LX52’’Wx74’’H | 50''Lx52''Wx74''H | 66''Lx68''Wx90''H |
Hopper Opening | 20''x20'' | 25’’x25’’ | 25''x25'' | 25''x25'' |
Mounting System | 3 Point Hitch | 3 Point Hitch | 3 Point Hitch | 3 Point Hitch |
Hopper Discharge Rotation | 360 | 360 | 360 | 360 |
Hopper Discharge Height | 60'' | 74’’ | 74'' | 90'' |
Net Weight | 195kg | 350kg | 448kg | 625kg |
Gross Weight | 215kg | 370kg | 468kg | 650kg |
Tractor HP | 18-30hp | 30-100hp | 30-100hp | 65-100hp |
20”/40” Container | 26/52 pcs | 10/20pcs | 10/20 pcs | 10/20 pcs |
Detailed Images
1.Transmission: By PTO linkage
2.Cast Blades:keeping a sharp cutting edge and maximizing the performance of the chipper. They are made of special material, with over times heat treatment process to ensure great working performance
3.The suspension plate shape is made by laser cutting,molding location
4. Use powder painting
5.Labels are:water proof, damp proof, mould proof, anti-ultraviolet radiation
Packaging & Shipping
Company Information
RIMA is established in 2009,located in Xibeiyu Industry Zone,Laizhou,Shandong,China.
With its strong technique power,complete set of manufacture equipments and experimental devices,advanced CAD R&D means, the company has complete production capaicty from cutting,profiling,welding,maching,paiting to packing.
RIMA has aleady manufactured a full range of high quality implements for the small to medium-sized tractor owners across the world,Such as Front End loader, Backhoe, Mower, rotary tiller, Wood Chipper, Log Splitter, Post Hole Diggers. more than 50 serials and more than 150 models of various implements.
