Cylindrical Compact Inductive Proximity Sensor Shielded type GX FL15A for PANASONIC
- Category: >>>
- Supplier: Shenzhen Smart-Tech Automation Equipment Co. Ltd.
Share on (62214446962):
Product Overview
Description
As of July 19, 2019
Specifications and design of the products are subject to change without notice for the product improvement.
Spec Detail
| Item | Specifications |
|---|---|
| Product Number | GX-3S |
| Part Number | GX-3S |
| CE marking directive compliance | EMC Directive, RoHS Directive |
| Max. operation distance | 0.8 mm 0.031 in plus or minus 15% (Note) The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object. The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. |
| Stable sensing range | 0 to 0.6 mm 0 to 0.024 in (Note) The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object. The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient temperature drift and/or supply voltage fluctuation. |
| Standard sensing object | Iron sheet 5 × 5 × t 1 mm 0.197 × 0.197 × t 0.039 in |
| Hysteresis | 15 % or less of operation distance (with standard sensing object) |
| Repeatability | 20 microm 0.787 mil or less |
| Supply voltage | 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
| Current consumption | 15 mA or less |
| Output | NPN open-collector transistor - Maximum sink current: 50 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 0.4 V or less (at 50 mA sink current) |
| Output:Utilization category | DC-12 or DC-13 |
| Output:Output operation | Normally open |
| Output:Short-circuit protection | - |
| Max. response frequency | 1kHz |
| Operation indicator | Red LED (lights up when the output is ON) |
| Protection | IP67 (IEC) |
| Ambient temperature | -25 to + 70 ℃ -13 to +158℉, Storage: -25 to +80 ℃ -13 to +176℉ |
| Ambient humidity | 35 to 95 % RH, Storage: 35 to 95 % RH |
| Voltage withstandability | 500 V AC for one min. between all supply terminals connected together and enclosure |
| Insulation resistance | 5 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure |
| Vibration resistance | 10 to 55 Hz frequency, 1.5 mm 0.059 in double amplitude in X, Y and Z directions for two hours each |
| Shock resistance | 200 m/s2 acceleration (20 G approx.) in X, Y and Z directions ten times each |
| Sensing range variation:Temperature characteristics | Over ambient temperature range -25 to +70 ℃ -13 to +158℉: Within ±20 % of sensing range at +20 ℃ +68℉ |
| Sensing range variation:Voltage characteristics | Within ±2 % for plus or minus10 % fluctuation of the supply voltage |
| Material | Enclosure: Stainless steel (SUS304), Resin part: TPX |
| Cable | 0.08 mm2 3-core oil, heat and cold resistant cabtyre cable, 3 m 9.843 ft long |
| Cable extension | Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable. |
| Weight | Net weight: 30 g approx. |
| Accessories | MS-SS3 (Sensor mounting bracket): 1 pc. MS-SS3-2 (C bracket): 1 pc. |
